Aluminum Electrolytic Capacitors
TS-HC Series
105°C, 2000 hours
Long life with high capacitance (30% smaller than HB series)
2 and 3 pin versions available
RoHS compliant PVC and RoHS compliant PET sleeve options
Rated Working Voltage:
Operating Temperature:
Nominal Capacitance:
Capacitance Tolerance:
Dissipation Factor:
(120 Hz, +20°C)
Leakage Current:
Ripple Current Multipliers:
10 ~ 250 VDC
-40 ~ +105°C
270 ~ 100000µF
± 20%
Working Voltage [V]:
Max. D.F. (%):
10
55
16
45
25
35
35
30
50
25
63
20
80
17
100 ~ 450
15
RoHS
Compliant
350 ~ 450 VDC
-25 ~ +105°C
100 ~ 1000µF
For capacitance values > 33000µF, add the value of:
(rated cap. [µF] - 33000 )
1000
3 CV (µA) max. after 5 minutes;
C = Capacitance in µF, V = WV
Frequency(Hz):
16~100WV:
160~450WV:
50
0.93
0.75
60
0.95
0.8
100~120
1.0
1.0
500
1.05
1.2
1k
1.08
1.25
10k
1.15
1.4
Ripple Current Ambient Temperature Factors*
Temperature (°C): 105°C
85°C
70°C
60°C
Multiplier: 1.0
1.7
2.0
2.2
45°C
2.35
Endurance:
2000 hours at +105°C with maximum specified ripple current (see page 4)
*Use of temperature ripple current multipliers may limit life to the hours specified for the maximum operating temperature.
Part Number System
E
E
T
H
C
Capacitance
Code
Sleeving Options: See Part Number listings
Diameter / Terminal Code
2
3
4.0±0.5mm
4.0±0.5mm
H
P
J
Q
K
R
L
S
Common
Code
Series
Code
1A
10
1C
16
1E
25
1V
35
1H
50
1J
63
Dimensions in millimeters
2 Pin Mounting Style
Diameter
Voltage Code
1K 2A 2C 2D 2E 2V 2G 2S 2W
80 100 160 200 250 350 400 420 450
# of pins:
pin length "T":
22mm
25mm
30mm
35mm
2
6.3±1mm
B
C
D
E
10.0±0.1
Circuit Board Mounting Holes
L+2 max.
T
D+1 max.
2 x Ø2.0±0.1
10.0±0.1
Circuit Board Mounting Holes
Ø2.0±0.1
4.75±0.1
3.3±0.1
3 Pin Mounting Style
L+2 max.
T
D+1 max.
Ø2.0±0.1
Ø2.5 min.
Pin Dimensions
2.0 max.
0.8
-0.1
3.5
1.5±0.2
+0.2
2.0 max.
0.8
-0.1
+0.2
Top of Capacitor Body
4.0±0.5
1.5±0.2
4.0
6.3±1.0
4mm Length: Standard on 2 and 3 Pin Mounting Styles
6.3mm Length: Available on 2 Pin Mounting Style Only
30
Design and specifications are subject to change without notice.
