Part Number

Search

396PH1-19-MT-.528/1.180

Description
Board Connector, 19 Contact(s), 1 Row(s), Male, Straight, 0.156 inch Pitch, Wire Wrap Terminal, Black Insulator, Receptacle
CategoryThe connector    The connector
File Size78KB,1 Pages
ManufacturerAdam Tech
Download Datasheet Parametric View All

396PH1-19-MT-.528/1.180 Overview

Board Connector, 19 Contact(s), 1 Row(s), Male, Straight, 0.156 inch Pitch, Wire Wrap Terminal, Black Insulator, Receptacle

396PH1-19-MT-.528/1.180 Parametric

Parameter NameAttribute value
Dielectric withstand voltage1000VAC V
Filter functionNO
Insulation resistance1000000000 Ω
Maximum operating temperature105 °C
Minimum operating temperature-40 °C
GuidelineUL
Is SamacsysN
YTEOL0
Objectid304949761
Reach Compliance CodeCompliant
ECCN codeEAR99
Body/casing typeRECEPTACLE
Connector typeBOARD CONNECTOR
Contact resistance20 mΩ
PCB row number1
Terminal pitch3.9624 mm
Contact to complete cooperationSN ON NI
Number of rows loaded1
Rated current (signal)8 A
Other featuresROHS COMPLIANT
Contact point genderMALE
insulator materialGLASS FILLED LIQUID CRYSTAL POLYMER
Installation methodSTRAIGHT
Installation typeBOARD
Total number of contacts19
subject depth0.125 inch
body length2.964 inch
Terminal length0.528 inch
Plug contact pitch0.156 inch
Number of connectorsONE
PCB contact patternRECTANGULAR
Contact completed and terminatedTIN OVER NICKEL
Contact materialBRASS
contact modeRECTANGULAR
Insulator colorBLACK
Contact styleSQ PIN-SKT
Mixed contactsNO
Termination typeWIRE WRAP
