Part Number

Search

PS-30PF-D4T1-PKL3

Description
Board Connector, 30 Contact(s), 2 Row(s), Male, Straight, 0.1 inch Pitch, Solder Terminal, Receptacle
CategoryThe connector    The connector
File Size196KB,1 Pages
ManufacturerJapan Aviation Electronics Industry Limited
Download Datasheet Parametric View All

PS-30PF-D4T1-PKL3 Overview

Board Connector, 30 Contact(s), 2 Row(s), Male, Straight, 0.1 inch Pitch, Solder Terminal, Receptacle

PS-30PF-D4T1-PKL3 Parametric

Parameter NameAttribute value
Filter functionNO
GuidelineUL
UL Flammability Code94V-0
Reach Compliance CodeUnknown
ECCN codeEAR99
Is SamacsysN
YTEOL2
Objectid301631731
body width0.2 inch
subject depth0.098 inch
body length1.5 inch
Terminal length0.118 inch
Contact point genderMALE
Installation methodSTRAIGHT
Installation typeBOARD
PCB row number2
Number of rows loaded2
Contact to complete cooperationAU ON NI
insulator materialPOLYPHENYLENE SULFIDE
Terminal pitch2.54 mm
Total number of contacts30
Connector typeBOARD CONNECTOR
Insulator colorBLACK
Plug contact pitch0.1 inch
Mixed contactsNO
Installation option 1LOCKING
PCB contact row spacing2.54 mm
Contact completed and terminatedGOLD
contact modeRECTANGULAR
Contact styleSQ PIN-SKT
PCB contact patternRECTANGULAR
Contact materialPHOSPHOR BRONZE
OptionsGENERAL PURPOSE
Match contact row spacing0.1 inch
Number of connectorsONE
Plating thickness30u inch
Termination typeSOLDER
2013/08/08
