Maximum Insulator Temperature 191°C (solder wave process only)
UL File No.: E68080
3
Electronic Solutions Division
Interconnect Solutions
http://www.3Mconnector.com/
3M is a trademark of 3M Company.
For technical, sales or ordering information call
800-225-5373
3M
™
DIN R-Form Socket
Right Angle, Solder Tail Termination
Table 1
Contact
Quantity
16
32
48
32
16
32
64
96
64
32
40
80
120
80
40
DIN 41612 Series
Part Number
DIN-016RSA-XXX-XXXX
DIN-032RSB-XXX-XXXX
DIN-048RSC-XXX-XXXX
DIN-032RSD-XXX-XXXX
DIN-016RSE-XXX-XXXX
DIN-032RSA-XXX-XXXX
DIN-064RSB-XXX-XXXX
DIN-096RSC-XXX-XXXX
DIN-064RSD-XXX-XXXX
DIN-032RSE-XXX-XXXX
DIN-040RSA-XXX-XXXX
DIN-080RSB-XXX-XXXX
DIN-120RSC-XXX-XXXX
DIN-080RSD-XXX-XXXX
DIN-040RSE-XXX-XXXX
A
53.40[2.102]
53.40[2.102]
53.40[2.102]
53.40[2.102]
53.40[2.102]
94.00[3.701]
94.00[3.701]
94.00[3.701]
94.00[3.701]
94.00[3.701]
114.32[4.501]
114.32[4.501]
114.32[4.501]
114.32[4.501]
114.32[4.501]
B
44.40[1.748]
44.40[1.748]
44.40[1.748]
44.40[1.748]
44.40[1.748]
85.00[3.346]
85.00[3.346]
85.00[3.346]
85.00[3.346]
85.00[3.346]
105.32[4.146]
105.32[4.146]
105.32[4.146]
105.32[4.146]
105.32[4.146]
C
48.26[1.900]
48.26[1.900]
48.26[1.900]
48.26[1.900]
48.26[1.900]
88.90[3.500]
88.90[3.500]
88.90[3.500]
88.90[3.500]
88.90[3.500]
109.22[4.300]
109.22[4.300]
109.22[4.300]
109.22[4.300]
109.22[4.300]
D
38.10[1.500]
38.10[1.500]
38.10[1.500]
38.10[1.500]
38.10[1.500]
78.74[3.100]
78.74[3.100]
78.74[3.100]
78.74[3.100]
78.74[3.100]
99.06[3.900]
99.06[3.900]
99.06[3.900]
99.06[3.900]
99.06[3.900]
E
Ø2.60[Ø.102]
Ø2.60[Ø.102]
Ø2.60[Ø.102]
Ø2.60[Ø.102]
Ø2.60[Ø.102]
Ø2.60[Ø.102]
Ø2.60[Ø.102]
Ø2.60[Ø.102]
Ø2.60[Ø.102]
Ø2.60[Ø.102]
Ø2.80[Ø.110]
Ø2.80[Ø.110]
Ø2.80[Ø.110]
Ø2.80[Ø.110]
Ø2.80[Ø.110]
F
0.25[.010]
0.25[.010]
0.25[.010]
0.25[.010]
0.25[.010]
0.25[.010]
0.25[.010]
0.25[.010]
0.25[.010]
0.25[.010]
0.60[.024]
0.60[.024]
0.60[.024]
0.60[.024]
0.60[.024]
10.60
[.417]
8.50
[.335]
10.20
[.402]
2.54
[.100]
5.08
[.200]
E
C
2.54
[.100]
F
3.00 ± .250
[.118]
6.00
[.236]
A
B
mm
[inch]
Tolerance Unless Noted
X.
mm
± 0.50
.X
± 0.25
.XX
± 0.15
5.08
[.200]
1.00
[.039]
D
[ ] Dimension for Reference Only
2.95
[.116]
3.80
(.150)
WITHOUT RETENTION CLIP
SR1
WITH “B” RETENTION CLIPS
for .062 PCB thickness
RR1L
for .062 and .093 PCB thickness
WITH “A” RETENTION CLIP
RR1
TS-2308-E
Sheet 2 of 3
3
Electronic Solutions Division
Interconnect Solutions
http://www.3Mconnector.com/
3M is a trademark of 3M Company.
For technical, sales or ordering information call
800-225-5373
3M
™
DIN R-Form Socket
Right Angle, Solder Tail Termination
DIN 41612 Series
2.54
[.100]
Ø0.94-1.09
[.037-.043]
2.54
[.100]
5.08
[.200]
5.30
[.209]
D
C
Ø2.8-2.9
[.110-.114]
Ordering Information
DIN - XXXRS X - XXX - XX
Contact Quantity
SEE TABLE 1
A = A Row only (see note)
B = Rows A & C Filled
C = Rows A,B & C Filled
D = Rows A & B Filled
E = B Row only (see note)
Plating Options:
SH = 1 - 3 μ” Gold on Contact
120 - 200 μ” Matte Tin on Terminal
FJ = 10 - 20 μ” Gold on Contact
120 - 200 μ” Matte Tin on Terminal
KR = 30 - 40 μ” Gold on Contact
120 - 200 μ” Matte Tin on Terminal
HM = 3 μ” Gold on Contact, 7 μ” Min. PdNi
120 - 200 μ” Matte Tin on Terminal
Termination Options:
SR1 = 3.00 [.118]
RR1L = 3.00 [.118] with ‘B’ retention clips
RR1 = 3.00 [.113] with “A” retention clip
Note: A and E options are currently not covered in UL File No. E68080
• This diagram serves only for Part Number descriptive definitions.
PLEASE CONTACT YOUR LOCAL SALES REPRESENTATIVE FOR CUSTOMER SPECIFIC PRODUCT CONFIGURATIONS.
TS-2308-E
Sheet 3 of 3
3
Electronic Solutions Division
Interconnect Solutions
http://www.3Mconnector.com/
3M is a trademark of 3M Company.
For technical, sales or ordering information call
800-225-5373
Important Notice
All statements, technical information, and recommendations related to 3M’s products are based on information believed to be reliable, but the accuracy or completeness
is not guaranteed. Before using this product, you must evaluate it and determine if it is suitable for your intended application. You assume all risks and liability associated
with such use. Any statements related to the product which are not contained in 3M’s current publications, or any contrary statements contained on your purchase order
shall have no force or effect unless expressly agreed upon, in writing, by an authorized officer of 3M.
Warranty; Limited Remedy; Limited Liability.
This product will be free from defects in material and manufacture for a period of one (1) year from the time of purchase.
3M MAKES NO OTHER WARRANTIES
INCLUDING, BUT NOT LIMITED TO, ANY IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE.
If this product is defective within the
warranty period stated above, your exclusive remedy shall be, at 3M’s option, to replace or repair the 3M product or refund the purchase price of the 3M product.
Except
where prohibited by law, 3M will not be liable for any indirect, special, incidental or consequential loss or damage arising from this 3M product, regardless of
