Printed-circuit board connector - MSTBV 2,5/ 4-GF-5,08 EX - 1796348
Please be informed that the data shown in this PDF Document is generated from our Online Catalog. Please find the complete data in the user's
documentation. Our General Terms of Use for Downloads are valid
(http://phoenixcontact.com/download)
PCB headers, nominal current: 12 A, nominal current (Ex): 12 A, nominal voltage (Ex): 176 V, number of
positions: 4, pitch: 5.08 mm, color: green, contact surface: Tin, mounting: Wave soldering
The figure shows a 10-position
version of the product
Key Commercial Data
Packing unit
GTIN
GTIN
4046356636452
50 pc
Technical data
Dimensions
Length [ l ]
Width
Pitch
Dimension a
Width [ w ]
Height [ h ]
Height
Length of the solder pin
Length
8.6 mm
30.48 mm
5.08 mm
15.24 mm
30.48 mm
15.9 mm
12 mm
3.9 mm
8.6 mm
General
Range of articles
Insulating material group
Rated voltage (III/3)
Connection in acc. with standard
Nominal current I
N
Insulating material
MSTBV 2,5/..-GF-EX
I
250 V
EN-VDE
12 A
PA
11/12/2018 Page 1 / 3
https://www.phoenixcontact.com/pi/products/1796348
Printed-circuit board connector - MSTBV 2,5/ 4-GF-5,08 EX - 1796348
Technical data
General
Flammability rating according to UL 94
Color
Number of positions
V0
green
4
Standards and Regulations
Connection in acc. with standard
Flammability rating according to UL 94
EN-VDE
V0
Environmental Product Compliance
REACh SVHC
China RoHS
Lead 7439-92-1
Environmentally Friendly Use Period = 50
For details about hazardous substances go to tab “Downloads”,
Category “Manufacturer's declaration”
Drawings
Drilling diagram
a
5,08
5,08
7,62
Dimensional drawing
15
a+15,24
2,4
3,8
22
12
3,9
1,4
3,8
8,6
5,08
5,08
a
7,62
Approvals
Approvals
Approvals
EAC / cULus Recognized
Ex Approvals
IECEx / ATEX / EAC Ex
Approval details
EAC
B.01742
11/12/2018 Page 2 / 3
https://www.phoenixcontact.com/pi/products/1796348
Printed-circuit board connector - MSTBV 2,5/ 4-GF-5,08 EX - 1796348
Approvals
cULus Recognized
Nominal voltage UN
Nominal current IN
D
http://database.ul.com/cgi-bin/XYV/template/LISEXT/1FRAME/index.htm E60425-19931011
B
300 V
15 A
150 V
15 A
