801-41-030-61-001000 datasheet, PDF

Datasheet> All Categories > The connector> The connector> 801-41-030-61-001000

801-41-030-61-001000: DescriptionBoard Connector; CategoryThe connector The connector; File Size710KB，1 Pages; ManufacturerMill-Max; Websitehttps://www.mill-max.com; Environmental Compliance

Download Datasheet Parametric View All

801-41-030-61-001000 Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	801-41-030-61-001000	-	-	View	Buy Now

801-41-030-61-001000 Overview

Board Connector

801-41-030-61-001000 Parametric

Parameter Name	Attribute value
JESD-609 code	e3
Is it lead-free?	Yes
Is it Rohs certified?	Yes
Country Of Origin	USA
ECCN code	EAR99
Is Samacsys	N
YTEOL	9
Objectid	1334425554
Reach Compliance Code	Compliant
body length	3 inch
Terminal length	0.104 inch
body width	0.1 inch
subject depth	0.276 inch
Contact to complete cooperation	NOT SPECIFIED
Installation method	STRAIGHT
Terminal pitch	2.54 mm
Body/casing type	SOCKET
Connector type	BOARD CONNECTOR
Contact point gender	FEMALE
insulator material	POLYETHYLENE
Installation type	BOARD
PCB row number	1
Number of rows loaded	1
Total number of contacts	30
Plug contact pitch	0.1 inch
Number of connectors	ONE
Termination type	PRESS FIT
Contact completed and terminated	Tin (Sn)
contact mode	RECTANGULAR
Plug information	MULTIPLE MATING PARTS AVAILABLE
Mixed contacts	NO
Installation option 1	LOCKING
Options	GENERAL PURPOSE
PCB contact pattern	RECTANGULAR
Plating thickness	10u inch
Contact material	NOT SPECIFIED
Contact style	RND PIN-SKT
Filter function	NO

Preview

Download Datasheet

View All

INTERCONNECTS

SERIES 800 & 801 • 2,54 GRID (0,76 DIA. PINS),

SOLDERLESS PRESS-FIT • SINGLE ROW STRIPS

Number of Pins

X 2,54

2,54

•

The unique compliant tail pins conform to

1,02

0,76 finished hole without stressing

inner layers. Patent No. 4,799,904

thicknesses of 1,52 - 2,54 and 2,29 - 3,3.

See ordering information for details

0,76 DIA.

4,85

•

Headers and sockets are available for board

2,64

2,79

1,14 DIA.

•

Series 800 pin headers use MM #5601 and

2,54

0,89 DIA.

0,46

SLOT

#5602 compliant tail pins featuring a 0,76

dia. mating lead. See page 220 for details

•

Series 801 sockets MM #4614 or #4615 use

FIG. 1

2,54

Number of Pins

X 2,54

Hi-Rel, 6-finger BeCu #47 contact rated at

4.5 amps. Receptacles accept 0,76 diameter

pins & 0,64 square pins. See pg. 256 for details

•

Insulators are high temperature thermoplastic

0,76 DIA.

4,85

ORDERING INFORMATION

Compliant Tail Pin Header for 1,52 - 2,54 Thick Boards

3,63

2,79

1,14 DIA.

FIG. 1

2,54

800-XX-0_ _-61-001000

Specify number of pins

01-64

0,89 DIA.

0,46

SLOT

Compliant Tail Pin Header for 2,29 - 3,3 Thick Boards

FIG. 2

0,64-0,94

0,64 * 0,64

2,54

Number of Pins

X 2,54

FIG. 2

RoHS - 2

800-XX-0_ _-62-001000

Specify number of pins

XX=Plating Code

See Below

0,25μm

01-64

For

Electrical, Mechanical

& Enviromental Data,

See page 264

2011/65/EU

2,24

6,1

7,01

SPECIFY PLATING CODE XX=

2,64

5,08μm

Sn/Pb

5,08μm

1,14 DIA.

Pin Plating

2,54

1,02 DIA.

0,46

SLOT

Compliant Tail Socket for 1,52 - 2,54 Thick Boards

FIG. 3

0,64-0,94

0,64 * 0,64

FIG. 3

801-XX-0_ _-61-001000

Specify number of pins

01-50

Compliant Tail Socket for 2,29 - 3,3 Thick Boards

Number of Pins

X 2,54

PAGE 56 | INTERCONNECTS

2,54

FIG. 4

RoHS - 2

801-XX-0_ _-62-001000

Specify number of pins

01-50

For

Electrical, Mechanical

& Enviromental Data,

See page 264

2,24

6,1

7,01

1,14 DIA.

3,63

2011/65/EU

XX=Plating Code

See Below

1,02 DIA.

0,46

SLOT

2,54

SPECIFY PLATING CODE XX=

Sleeve

(Pin)

Contact

(Clip)

5,08μm

Sn/Pb

5,08μm

Sn/Pb

5,08μm

Sn/Pb

5,08μm

FIG. 4

0,25μm

0,76μm

2,54μm

Sn/Pb

0,25μm

0,76μm

Mill-Max Mfg. Corp. • 190 Pine Hollow Road, P.O. Box 300, Oyster Bay, NY 11771 • 516-922-6000 • Fax: 516-922-9253 • www.mill-max.com
