Series 30AC
Regulated 30 Watt ACDC Switchers
Hi Reliability Hi Efficiency/Isolated Single, Dual, and Triple Outputs
Features
Typical Characteristics
Test Conditions: 25º C ambient
Input Voltage: 90130 VAC OR 170 240 VAC (47440
Hz)
Line/Load Regulation: See specifications below
Converter Frequency: 2535 KHz typ
Operating Temperature: 25º C to +70º C ambient
Output Voltage Temperature Coefficient: 0.02% / º C
Storage Temperature: 55º C. to +125º C
Isolation: 1200 VRMS
Short Circuit Protection: Continuous
This series of low profile 30 Watt AC to DC switchers come in
12 different models. These offer high efficiency and precise
regulation throughout the operating temperature range of 25º C
to +70º C ambient, with no heat sink or electrical heating
required. The 30AC Series keeps a maximum of 0.500" height
while still offering you 1200 volts RMS isolation in a rugged
encapsulated case. The convenience of PC mounting and the
availability of three outputs should aid your circuit design.
Low profile 0.500"
Low weight
Encapsulated semiconductors,
conservatively rated for maximum
reliability
Excellent voltage regulation
Excellent load regulation
Up to 30 watts output power at 70º
C ambient
Low output ripple
Isolation: 1200V RMS
Single, dual and triple outputs
No heat sink required
Miniature size
No output capacitor required
Shielding
Low Capacity Option: All units can be
manufactured with isolation capacity of
70pF. Contact factory.
SERIES 30AC SINGLE OUTPUT
SERIES 30AC DUAL OUTPUT
Note: Recommended torque for mounting screws is 3 to Note: The recommended torque for mounting screws is 3
5 InLbs.
to 5 In.Lbs.
Larger Size Drawing And Schematic
Larger Size Drawing And Schematic
Series 30AC Single Output
Input Voltage 90130 VAC (47440Hz)
(Optional 170240VAC, 47440 Hz)***
Max.
Pico Output
Load
Part Voltage
Current
No. (VDC)
(mA)
30AC5S
30AC12S
30AC15S
30AC24S
30AC28S
5
12
15
24
28
5000
2500
2000
1250
1070
Max.
Output
Power
(watts)
25
30
30
30
30
Output
EFF @
Voltage
Full
Ripple @
Load
Full Ld.
Typical
11 MHz BW
(%)*
mv pp
75
81
82
83
83
50
50
50
50
50
Output
Voltage
Tolerance
(± %)*
0.5
0.5
0.5
0.5
0.5
V LD.
Reg.
10%
100%
Load**
(± %)*
0.5
0.5
0.5
0.5
0.5
Line
Price
Regulation (US
(± %)*
$)
0.2
0.2
0.2
0.2
0.2
376.56
376.56
376.56
376.56
376.56
*Readings Taken at 115VAC60Hz. at full load
**10% minimum load required
***All units available with 170240VAC input. Add H prefix to part number $40 per unit cost added.
Series 30AC Dual Output
Input Voltage 90130VAC (47440Hz)
(Optional 170240VAC, 47440 Hz)***
Max.
Load
Output
Current
Voltage
(mA)
(VDC)
per
output
± 5
± 12
± 15
2500
1250
1000
Pico
Part
No.
Max.
Output
Power
(watts)
per
output
12.5
15
15
Output
EFF @
Voltage
Full
Ripple @
Load
Full Ld.
Typical
11 MHz BW
(%)*
mv pp
76
78
80
50
50
50
Output
Voltage
Tolerance
(± %)*
at full
load
each
output
0.5
0.5
0.5
V LD.
Reg.
10%
100%
Load**
(± %)*
0.5
0.5
0.5
Line
Regulation
(± %)* Price
at full
(US
load
$)
each
output
0.2
0.2
0.2
420.64
420.64
420.64
30AC5D
30AC12D
30AC15D
*Readings Taken at 115VAC60Hz.
**10% minimum load required
***All units available with 170240VAC input. Add H prefix to part number $40 per unit cost added.
SERIES 30AC TRIPLE OUTPUT
Options Available per MILSTD883:
Expanded Operating temperature (55º C to
+85º C)
Stabilization Bake: (125º C ambient)
Temperature Cycle: 55º C. to +125º C
Hi Temp, Burn in
Note: The recommended torque for moutning screws is 3
to 5 In.Lbs.
Larger Size Drawing And Schematic
Series 30AC Triple Output
Input Voltage 90130VAC (47440Hz)
(Optional 170240VAC, 47440 Hz)***
.
Main Output Voltage
V
LD.
Reg.
25%
100%
Load
(±
%)*
0.5
0.5
0.5
0.5
Auxiliary Output Voltage
Output
Voltage
Ripple
@
Full Ld.
11
MHz
BW
mv pp
50
50
50
50
.
Pico
Part
No.
Output Max. Max.
Voltage Load Output
DC Current Power
(VDC) (mA) (watts)
Output
Voltage
(DC)
Per
Output
Max.
Load
Current
(mA)
Per
Output
Max.
Output
Power
(watts)
Per
Output
Volt.
Load
Reg.
25%
100%
Load**
(± %)*
Output
Ripple
@
EFF @
Full
Full Price
Ld.
Load (US
11
Typical $)
MHz
(%)
BW
mv p
p*
50
50
50
50
78
78
80
80
464.71
464.71
464.71
464.71
30AC5T12
30AC5T15
30AC12T5
30AC15T5
5
5
12
15
4000
4000
2080
1660
20
20
25
25
± 12
± 15
± 5
± 5
208
166
500
500
2.5
2.5
2.5
2.5
5
5
5
5
.
Common Characteristics
Main Output Voltage Tolerance ± 0.5%
Main Line Regulation ± 0.2%
Common Characteristics
Auxiliary Output Voltage Tolerance ± 5%
Auxillary Line Regulation ± 0.2%
.
*Measurements Taken at 115VAC60Hz.
**10% minimum load required
***All units available with 170240VAC input. Add H prefix to part number $40 per unit cost added.
For immediate engineering assistance or to place an order:
Call Toll Free: 8004311064
PICO Electronics, Inc.
143 Sparks Ave. Pelham, NY 108031810
Tel: 9147381400
Fax: 9147388225
