1-1676950-7 datasheet, PDF - EEWORLD Datasheet

1-1676950-7: Description1 ELEMENT, 2200uH, GENERAL PURPOSE INDUCTOR, SMD, ROHS COMPLIANT; File Size100KB，1 Pages; ManufacturerTE Connectivity; Websitehttp://www.te.com; Environmental Compliance

Download Datasheet Parametric Compare View All

1-1676950-7 Overview

1 ELEMENT, 2200uH, GENERAL PURPOSE INDUCTOR, SMD, ROHS COMPLIANT

1-1676950-7 Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
Objectid	1646063001
Reach Compliance Code	unknown
ECCN code	EAR99
YTEOL	0
DC Resistance	32 Ω
Nominal inductance(L)	2200 µH
Inductor Applications	POWER INDUCTOR
Inductor type	GENERAL PURPOSE INDUCTOR
Number of functions	1
Number of terminals	4
Minimum quality factor (at nominal inductance)	95
Maximum rated current	0.055 A
Shape/Size Description	RECTANGULAR PACKAGE
shield	YES
surface mount	YES
Terminal location	DUAL IN-LINE
Terminal shape	GULL WING
Tolerance	20%

Preview

Download Datasheet

View All

C orporate Hom e

Electronic Components

Se gm e nts

W ho W e Are

My Account

Searc h

Products

Documentation

Resources

My Account

Customer Support

Home

Products

By Type

Passive C omponents

Product Feature Selector

> Product Details

3636A222MT Product Details

Live Product Chat

Inductors

Always EU R oHS/ELV C om plia nt

(

Sta te m e nt of C om plia nce

)

Quick Links

C heck Pricing & Availability

Search for Tooling

Product Feature Selector

C ontact Us About This Product

3636A222MT

(1-1676950-7)

T E I nternal N umber: 1 - 1 6 7 6 9 5 0 - 7

Product Highlights:

Inductor

Inductor Type = Shielded Power Wirewound

Lead Type = Surface Mount Terminals

Wirewound

Inductance = 2200 ?H

View all Features

A dd to M y P art L is t

Reques t Sample

Find Similar P roduc ts

Active

Buy P roduc t

Documentation & Additional Information

Product Drawings:

SHIELDED SMD POWER INDUC TORS SERIES 3636A

(PDF, English)

Catalog Pages/Data Sheets:

Shielded SMD Power Inductor - Type 3636 SeriesA - Ty...

(PDF, English)

Product Specifications:

None Available

Application Specifications:

None Available

Instruction Sheets:

None Available

CAD Files:

None Available

List all Documents

Product Features

(Please use the Product Drawing for all design activity)

Product Type Features:

Product Type

= Inductor

Inductor Type = Shielded Power Wirewound

Element

= Wirewound

Shielded

= Yes

Electrical Characteristics:

Inductance (?H)

= 2200

DC Resistance (?)

= 32

C urrent, Maximum (mA)

= 55

Quality Factor

= 95

Package Type

= Taped and Reeled

Tolerance (%) = 20

Body Related Features:

Lead Type

= Surface Mount Terminals

Series

= 3636

Package, C omponent Size

= 7.8 x 7.5

Mount Style

= Surface Mount

Industry Standards:

RoHS/ELV C ompliance

= RoHS compliant, ELV compliant

Lead Free Solder Processes

= Reflow solder capable to 245?C ,

Reflow solder capable to 260?C

RoHS/ELV C ompliance History = Always was RoHS compliant

Operation/Application:

Application

= Power C ircuitry

Other:

Brand = Sigma Inductors

Additional Information:

Product Line Information

1-1676950-7 Related Products

	1-1676950-7	3636A222MT
Description	1 ELEMENT, 2200uH, GENERAL PURPOSE INDUCTOR, SMD, ROHS COMPLIANT	1 ELEMENT, 32uH, GENERAL PURPOSE INDUCTOR, SMD, ROHS COMPLIANT
Is it Rohs certified?	conform to	conform to
Reach Compliance Code	unknown	unknown
ECCN code	EAR99	EAR99
DC Resistance	32 Ω	32 Ω
Nominal inductance(L)	2200 µH	32 µH
Inductor Applications	POWER INDUCTOR	POWER INDUCTOR
Inductor type	GENERAL PURPOSE INDUCTOR	GENERAL PURPOSE INDUCTOR
Number of functions	1	1
Number of terminals	4	4
Minimum quality factor (at nominal inductance)	95	95
Maximum rated current	0.055 A	0.055 A
Shape/Size Description	RECTANGULAR PACKAGE	RECTANGULAR PACKAGE
shield	YES	YES
surface mount	YES	YES
Terminal location	DUAL IN-LINE	DUAL IN-LINE
Terminal shape	GULL WING	GULL WING
Tolerance	20%	20%
