FEATURES
1N4916-1N4932A
19.2V LOW NOISE TEMPERATURE
COMPENSATED ZENER REFERENCE DIODE
Available as “HR” (high reliability) screened per MIL-PRF-19500, JANTX level. Add “HR” suffix to base part number.
Available as non-RoHS (Sn/Pb plating), standard, and as RoHS by adding “-PBF” suffix.
MAXIMUM RATINGS
Characteristics
Junction and storage temperatures
DC power dissipation
Power derating
Values
-65 to +175°C
500mW @ 50°C
4 mW/°C above 50°C
ELECTRICAL CHARACTERISTICS
(T
A
= 25°C unless otherwise specified)
Test current
Part number
I
ZT
Note 1
mA
1N4916
1N4916A
1N4917
1N4917A
1N4918
1N4918A
1N4919
1N4919A
1N4920
1N4920A
1N4921
1N4921A
1N4922
1N4922A
1N4923
1N4923A
1N4924
1N4924A
1N4925
1N4925A
1N4926
1N4926A
1N4927
1N4927A
1N4928
0.5
0.5
0.5
0.5
0.5
0.5
1.0
1.0
1.0
1.0
1.0
1.0
2.0
2.0
2.0
2.0
2.0
2.0
4.0
4.0
4.0
4.0
4.0
4.0
4.0
Maximum
voltage change
with temperature
ΔV
ZT
Note 2
Volts
0.144
0.298
0.072
0.149
0.029
0.060
0.144
0.298
0.072
0.149
0.029
0.060
0.144
0.298
0.072
0.149
0.029
0.060
0.144
0.298
0.072
0.149
0.029
0.060
0.014
°C
25 to +100
-55 to +100
25 to +100
-55 to +100
25 to +100
-55 to +100
25 to +100
-55 to +100
25 to +100
-55 to +100
25 to +100
-55 to +100
25 to +100
-55 to +100
25 to +100
-55 to +100
25 to +100
-55 to +100
25 to +100
-55 to +100
25 to +100
-55 to +100
25 to +100
-55 to +100
25 to +100
Temperature
range
Effective
temperature
coefficient
α
VZ
Note 3
±%/°C
0.01
0.01
0.005
0.005
0.002
0.002
0.01
0.01
0.005
0.005
0.002
0.002
0.01
0.01
0.005
0.005
0.002
0.002
0.01
0.01
0.005
0.005
0.002
0.002
0.001
Maximum
dynamic
impedance
Z
ZT
Note 4
Ohms
600
600
600
600
600
600
300
300
300
300
300
300
150
150
150
150
150
150
75
75
75
75
75
75
75
Maximum noise
density
N
D
µV/√Hz
1.0
1.0
1.0
1.0
1.0
1.0
0.5
0.5
0.5
0.5
0.5
0.5
0.25
0.25
0.25
0.25
0.25
0.25
0.22
0.22
0.22
0.22
0.22
0.22
0.22
Rev. 20150702
High-reliability discrete products
and engineering services since 1977
Maximum
voltage change
with temperature
ΔV
ZT
Note 2
Volts
0.030
0.144
0.298
0.072
0.149
0.029
0.060
0.014
0.030
1N4916-1N4932A
Temperature
range
Effective
temperature
coefficient
α
VZ
Note 3
°C
-55 to +100
25 to +100
-55 to +100
25 to +100
-55 to +100
25 to +100
-55 to +100
25 to +100
-55 to +100
±%/°C
0.001
0.01
0.01
0.005
0.005
0.002
0.002
0.001
0.001
Maximum
dynamic
impedance
Z
ZT
Note 4
Ohms
75
36
36
36
36
36
36
36
36
19.2V LOW NOISE TEMPERATURE
COMPENSATED ZENER REFERENCE DIODE
Maximum noise
density
N
D
µV/√Hz
0.22
0.20
0.20
0.20
0.20
0.20
0.20
0.20
0.20
Test current
Part number
I
ZT
Note 1
mA
1N4928A
1N4929
1N4929A
1N4930
1N4930A
1N4931
1N4931A
1N4932
1N4932A
4.0
7.5
7.5
7.5
7.5
7.5
7.5
7.5
7.5
Note 1. Nominal voltage for all types is 19.2 volts ±5%
Note 2. Referred to as the “box” measurement method, the
V
ZT
is the maximum voltage variance that will occur as the voltage is scanned through all
temperatures between the temperature range limits.
Note 3. The effective temperature coefficients are tabulated in %/°C primarily for information only because temperature compensated diodes inherently
have a non-linear voltage temperature relationship.
Note 4. The dynamic zener impedance Z
ZT
is derived from the resulting ac voltage developed when a 60Hz, rms, ac current equal to 10% of the dc zener
current I
ZT
is superimposed on I
ZT.
Note 5. To specify radiation hardened devices, use “RH” prefix instead of “1N”.
MECHANICAL CHARACTERISTICS
Case
Marking
Polarity
DO-35 hermetically sealed glass
Body painted, alpha numeric
Cathode band
Rev. 20150702
High-reliability discrete products
and engineering services since 1977
1N4916-1N4932A
19.2V LOW NOISE TEMPERATURE
COMPENSATED ZENER REFERENCE DIODE
Rev. 20150702
