CSM-8A
SMD CRYSTAL
The CSM-8A Series is a very cost effective, low profile SMD
quartz crystal. The glass sealed ceramic package is ideal for
PCMCIA, ethernet and fax modem card applications.
CSM-8A SMD CRYSTAL
Request a Sample
OPERATING CONDITIONS / ELECTRICAL CHARACTERISTICS
PARAMETERS
Frequency
Frequency Tolerance*
Frequency Stability*
Shunt Capacitance
Load Capacitance
Drive Level
Operating Temperature*
Storage Temperature
Aging (First Year)
@ +25°C
-10 ~ +70°C
CONDITIONS
MIN
CSM-8A
TYP
MAX
UNITS
100.000
± 30
± 50
5
MHz
ppm
ppm
pF
pF
µW
°C
°C
ppm
8.000
Co
Specify in P/N
D
L
T
opr
T
stg
@ +25°C ±3°C
Frequency (MHz)
Max.
9.800 ~ 15.999
16.000 ~ 42.000
35.000 ~ 100.000
ESR Ω
60
40
60
-10
-40
10
20
Series
500
+70
+85
±5
•
•
•
•
Glass Sealed Ceramic Package
Tight Stability/High Reliability
Wide Frequency Range
RoHS Compliant(7(c)I Exemption)
DIMENSIONS (mm)
Mode of Osc.
Fundamental
Fundamental
3
rd
Overtone
Figure 1)
Top, Side, and Bottom
Figure 2)
Suggested land
pattern
PART NUMBERING GUIDE: Example ECS-160-20-20A-TR
ECS - FREQUENCY ABBREVIATION
LOAD
CAPACITANCE
20 = 20 pF
S = Series
PACKAGE
Tolerance
20A =
CSM-8A
Blank = Std
A = ± 25
ppm
J = ± 20
ppm
R = ± 15
ppm
AVAILABLE OPTIONS
Stability
Blank= Std
D= ±100 ppm
E = ± 50 ppm
G = ± 30 ppm
H = ± 25 ppm
T = ± 20 ppm
†
W = ±15 ppm
†
PACKAGING
Temp Range
Blank= Std
L = -10 ~ +70°C
M = -20 ~ +70°C
Y = -30 ~ +85°C
N = -40 ~ +85°C
P = -40 ~ +105°C
TR =
Tape
& Reel
1K/Reel
ECS
160 = 16.000 MHz
See P/N Guide
* Specify available options in P/N.
†
Contact ECS for availability over extended temp range.
