3622A150MT

Description
1 ELEMENT, 15uH, FERRITE-CORE, GENERAL PURPOSE INDUCTOR, SMD
CategoryPassive components    inductor
File Size102KB,1 Pages
ManufacturerTE Connectivity
Websitehttp://www.te.com
Environmental Compliance
Download Datasheet Parametric Compare View All

3622A150MT Overview

1 ELEMENT, 15uH, FERRITE-CORE, GENERAL PURPOSE INDUCTOR, SMD

3622A150MT Parametric

Parameter NameAttribute value
Is it lead-free?Lead free
Is it Rohs certified?conform to
Reach Compliance Codeunknown
ECCN codeEAR99
core materialFERRITE
DC Resistance0.06 Ω
Nominal inductance(L)15 µH
Inductor ApplicationsPOWER INDUCTOR
Inductor typeGENERAL PURPOSE INDUCTOR
Manufacturer's serial number3622
Number of functions1
Number of terminals2
Maximum operating temperature80 °C
Minimum operating temperature-20 °C
self resonant frequency23 MHz
Shape/Size DescriptionCYLINDRICAL PACKAGE
shieldNO
surface mountYES
Terminal locationDUAL ENDED
Terminal shapeWRAPAROUND
Test frequency0.1 MHz
Tolerance20%
Base Number Matches1
C orporate Hom e
|
Electronic Components
|
Se gm e nts
|
W ho W e Are
My Account
Searc h
Products
Documentation
Resources
My Account
Customer Support
Home
>
Products
>
By Type
>
Passive C omponents
>
Product Feature Selector
> Product Details
3622A150MT Product Details
Live Product Chat
Inductors
C onve rte d to EU R oHS/ELV C om plia nt
(
Sta te m e nt of C om plia nce
)
Quick Links
C heck Pricing & Availability
Search for Tooling
Product Feature Selector
C ontact Us About This Product
3622A150MT
(1676958-4)
T E I nternal N umber: 1 6 7 6 9 5 8 - 4
Product Highlights:
l
Inductor
l
Inductor Type = Unshielded Power Wirewound
l
Lead Type = Surface Mount Terminals
l
Wirewound
l
Inductance = 15 ?H
View all Features
A dd to M y P art L is t
Reques t Sample
Find Similar P roduc ts
Active
Buy P roduc t
Documentation & Additional Information
Product Drawings:
l
POWER INDUC TORS SERIES 3622
(PDF, English)
Catalog Pages/Data Sheets:
l
Power Inductor - Type 3622 Series - Tyco Electronics...
(PDF, English)
Product Specifications:
l
None Available
Application Specifications:
l
None Available
Instruction Sheets:
l
None Available
CAD Files:
l
None Available
List all Documents
Product Features
(Please use the Product Drawing for all design activity)
Product Type Features:
l
Product Type
= Inductor
l
Inductor Type = Unshielded Power Wirewound
l
Element
= Wirewound
l
Shielded
= No
Electrical Characteristics:
l
Inductance (?H)
= 15
l
DC Resistance (?)
= 0.23
l
C urrent, Maximum (mA)
= 1000
l
Package Type
= Taped and Reeled
l
Tolerance (%) = 20
Body Related Features:
l
Lead Type
= Surface Mount Terminals
l
Series
= 3622
l
Package, C omponent Size
= 6.6 x 4.5
l
Mount Style
= Surface Mount
Industry Standards:
l
RoHS/ELV C ompliance
= RoHS compliant, ELV compliant
l
Lead Free Solder Processes
= Reflow solder capable to 245?C ,
Reflow solder capable to 260?C
l
RoHS/ELV C ompliance History = C onverted to comply with RoHS
directive
Operation/Application:
l
Application
= Power C ircuitry
Other:
l
Brand = Sigma Inductors
Additional Information:
l
Product Line Information
Related Products:
l
Tooling
Provide Website Feedback
|
Need Help?
Home
|
C ustomer Support
|
Suppliers
|
Site Map
|
Privacy Policy
|
Browser Support
©
2009 Tyco Electronics C orporation All Rights Reserved

3622A150MT Related Products

3622A150MT 1676958-4
Description 1 ELEMENT, 15uH, FERRITE-CORE, GENERAL PURPOSE INDUCTOR, SMD 1 ELEMENT, 15uH, GENERAL PURPOSE INDUCTOR, SMD, ROHS COMPLIANT
Is it lead-free? Lead free Lead free
Is it Rohs certified? conform to conform to
Reach Compliance Code unknown compli
ECCN code EAR99 EAR99
DC Resistance 0.06 Ω 0.23 Ω
Nominal inductance(L) 15 µH 15 µH
Inductor Applications POWER INDUCTOR POWER INDUCTOR
Inductor type GENERAL PURPOSE INDUCTOR GENERAL PURPOSE INDUCTOR
Manufacturer's serial number 3622 3622
Number of functions 1 1
Number of terminals 2 2
Shape/Size Description CYLINDRICAL PACKAGE RECTANGULAR PACKAGE
shield NO NO
surface mount YES YES
Terminal location DUAL ENDED DUAL ENDED
Terminal shape WRAPAROUND WRAPAROUND
Tolerance 20% 20%
Base Number Matches 1 1
