Document 160-1
Chip Inductors – 1008HS (2520)
Coilcraft “HS” series chip inductors have been designed
especially for the needs of today’s high frequency designer.
Their ceramic construction delivers the highest possible
Part
number
1
Inductance
2
(nH)
10
12
15
18
22
27
33
39
47
56
68
82
100
120
150
180
220
270
330
390
470
560
620
680
750
820
910
1000
@ 50 MHz
@ 50 MHz
@ 50 MHz
@ 50 MHz
@ 50 MHz
@ 50 MHz
@ 50 MHz
@ 50 MHz
@ 50 MHz
@ 50 MHz
@ 50 MHz
@ 50 MHz
@ 25 MHz
@ 25 MHz
@ 25 MHz
@ 25 MHz
@ 25 MHz
@ 25 MHz
@ 25 MHz
@ 25 MHz
@ 25 MHz
@ 25 MHz
@ 25 MHz
@ 25 MHz
@ 25 MHz
@ 25 MHz
@ 25 MHz
@ 25 MHz
Percent
tolerance
3
5
5
5
5
5
5,2
5,2
5,2
5,2,1
5,2,1
5,2,1
5,2,1
5,2,1
5,2,1
5,2,1
5,2,1
5,2,1
5,2,1
5,2,1
5,2,1
5,2,1
5,2,1
5,2,1
5,2,1
5,2,1
5,2,1
5,2,1
5,2
SRF and excellent Q values. The non-magnetic coilform
also ensures the utmost in thermal stability, predictability
and batch consistency.
Q
min
4
SRF min
5
(MHz)
4100
3300
2500
2500
2400
1600
1600
1500
1500
1300
1300
1000
1000
950
850
750
700
600
570
500
450
415
375
375
360
350
320
290
DCR max
6
(Ohms)
0.08
0.09
0.10
0.11
0.12
0.13
0.14
0.15
0.16
0.18
0.20
0.22
0.56
0.63
0.70
0.77
0.84
0.91
1.05
1.12
1.19
1.33
1.40
1.47
1.54
1.61
1.68
1.75
Irms
7
(mA)
1000
1000
1000
1000
1000
1000
1000
1000
1000
1000
1000
1000
650
650
580
620
500
500
450
470
470
400
300
400
360
400
380
370
1008HS-100T_L_
1008HS-120T_L_
1008HS-150T_L_
1008HS-180T_L_
1008HS-220T_L_
1008HS-270T_L_
1008HS-330T_L_
1008HS-390T_L_
1008HS-470T_L_
1008HS-560T_L_
1008HS-680T_L_
1008HS-820T_L_
1008HS-101T_L_
1008HS-121T_L_
1008HS-151T_L_
1008HS-181T_L_
1008HS-221T_L_
1008HS-271T_L_
1008HS-331T_L_
1008HS-391T_L_
1008HS-471T_L_
1008HS-561T_L_
1008HS-621T_L_
1008HS-681T_L_
1008HS-751T_L_
1008HS-821T_L_
1008HS-911T_L_
1008HS-102T_L_
50 @ 500 MHz
50 @ 500 MHz
50 @ 500 MHz
50 @ 350 MHz
55 @ 350 MHz
55 @ 350 MHz
60 @ 350 MHz
60 @ 350 MHz
65 @ 350 MHz
65 @ 350 MHz
65 @ 350 MHz
60 @ 350 MHz
60 @ 350 MHz
60 @ 350 MHz
45 @ 100 MHz
45 @ 100 MHz
45 @ 100 MHz
45 @ 100 MHz
45 @ 100 MHz
45 @ 100 MHz
45 @ 100 MHz
45 @ 100 MHz
45 @ 100 MHz
45 @ 100 MHz
45 @ 100 MHz
45 @ 100 MHz
35 @ 50 MHz
35 @ 50 MHz
1. When ordering, specify
tolerance, termination
and
packaging
codes:
1008HS-102TGLC
Tolerance: F
= 1%
G
= 2%
J
= 5%
(Table shows stock tolerances in bold.)
Termination: L
= RoHS compliant silver-palladium-platinum-glass frit.
Special order:
T
= RoHS tin-silver-copper (95.5/4/0.5)
or
S
= non-RoHS tin-lead (63/37).
Packaging: C
= 7″ machine-ready reel. EIA-481 embossed plastic
tape (2000 parts per full reel).
B
= Less than full reel. In tape, but not machine ready.
To have a leader and trailer added ($25 charge), use
code letter C instead.
D
= 13″ machine-ready reel. EIA-481 embossed plastic
tape. Factory order only, not stocked (7500 parts per
full reel).
2. Inductance measured using a Coilcraft SMD-A fixture in an Agilent/HP
4286A impedance analyzer with Coilcraft-provided correlation pieces.
3. Tolerances in bold are stocked for immediate shipment.
4. Q measured using an Agilent/HP 4291A with an Agilent/HP 16193 test
fixture.
5. SRF measured using an Agilent/HP 8753D network analyzer and a
Coilcraft SMD-D test fixture.
6. DCR measured on a Cambridge Technology micro-ohmmeter and a
Coilcraft CCF840 test fixture.
7. Current that causes a 15°C temperature rise from 25°C ambient.
8. Electrical specifications at 25°C.
9. Temperature coefficient of inductance: +25 to +125 ppm/°C.
For part marking data, please visit http://www.coilcraft.com/colrcode.cfm.
Refer to Doc 362 “Soldering Surface Mount Components” before soldering.
US
+1-847-639-6400 sales@coilcraft.com
UK
+44-1236-730595 sales@coilcraft-europe.com
Taiwan
+886-2-2264 3646 sales@coilcraft.com.tw
China
+86-21-6218 8074 sales@coilcraft.com.cn
Singapore
+ 65-6484 8412 sales@coilcraft.com.sg
Document 160-1
Revised 01/18/12
© Coilcraft Inc. 2013
This product may not be used in medical or high
risk applications without prior Coilcraft approval.
Specification subject to change without notice.
Please check web site for latest information.
Document 160-2
1008HS Series (2520)
Typical Q vs Frequency
100
90
100 nH
12 nH
Irms Derating
47 nH
120
110
100
Percent of rated
I
rms
80
70
60
50
40
30
20
10
0
10
100
90
80
70
60
50
40
30
20
10
0
-40
-20
0
20
40
60
80
100
120 140
Q factor
330 nH
750 nH
Ambient temperature (°C)
1000
10000
Frequency (MHz)
Typical L vs Frequency
1000
900
750 nH
800
700
Inductance (nH)
600
500
400
300
200
100
0
1
100 nH
47 nH
12 nH
10
100
1000
10000
330 nH
Core material
Ceramic
Terminations
RoHS compliant silver-palladium-platinum-glass frit.
Other terminations available at additional cost.
Weight
28.3 – 31.5 mg
Ambient temperature
–40°C to +125°C with
Irms
current, +125°C to
+140°C with derated current
Storage temperature
Component: –40°C to +140°C.
Tape and reel packaging: –40°C to +80°C
Resistance to soldering heat
Max three 40 second reflows at
+260°C, parts cooled to room temperature between cycles
Temperature Coefficient of Inductance (TCL)
+25 to +125 ppm/°C
Moisture Sensitivity Level (MSL)
1 (unlimited floor life at <30°C /
85% relative humidity)
Failures in Time (FIT) / Mean Time Between Failures (MTBF)
One per billion hours / one billion hours, calculated per Telcordia SR-332
Packaging
2000/7″reel; 7500/13″ reel Plastic tape: 8 mm wide,
0.23 mm thick, 4 mm pocket spacing, 1.3 mm pocket depth
PCB washing
Tested with pure water or alcohol only. For other solvents,
see Doc787_PCB_Washing.pdf.
B
overall
F
A
G
F
E
terminal
C
I
J
I
Terminal wraparound:
approx 0.015/0,38 both ends
25°C
H
Frequency (MHz)
Recommended
Land Pattern
H
2,54
I
1,02
J
1,27
mm
A
max
0.105
2,67
B
max
0.095
2,41
C
max
0.070
1,78
E
0.080
2,03
F
0.020
0,51
G
1,52
0.060 0.100 0.040 0.050 inches
Note:
Height dimension is before optional solder application. For maximum
height dimension including solder, add 0.006 in / 0,152 mm.
US
+1-847-639-6400 sales@coilcraft.com
UK
+44-1236-730595 sales@coilcraft-europe.com
Taiwan
+886-2-2264 3646 sales@coilcraft.com.tw
China
+86-21-6218 8074 sales@coilcraft.com.cn
Singapore
+ 65-6484 8412 sales@coilcraft.com.sg
Document 160-2
Revised 01/18/12
© Coilcraft Inc. 2013
This product may not be used in medical or high
risk applications without prior Coilcraft approval.
Specification subject to change without notice.
Please check web site for latest information.
