Positions
09
15
25
37
50
A
31.00
40.00
53.50
69.20
67.00
Dimensions
B
C
47.00 15.60
48.00 15.80
48.00 16.00
48.60 16.00
48.40 19.00
D
E
15.80 24.99
15.80 33.32
16.00 47.04
20.80
24.00
Positions
9
15
25
37
50
Cable Entry Diameter (mm) U Type
6
8
9.5
7
7
9
10.5
8
9
10
11
13
9
10
11.5 13.5 15.5
10
13
14
16
18
Positions
9
15
25
37
50
6
Cable Entry Diameter (mm) V Type
5.5 6 6.5
8.5
9
7 7.5 8
7
8
9
10 12
7
8
9
10 12 13 14.5
10 12 14 16
10 13 14.5 16 18
9.5
D
Standard
E
Standard
Cable Entry
XX
[blank]=Standard
06, 07, 08, 09, 10, 12,
13, 14, 16, 18
(See cable entry chart)
GT=With Grommet Tree
Screw
XX
SS=Standard screw
TS=Metal thumb screw
PS=Plastic thumb screw
Options
XX
[blank]=None
SNP=Snap together
(plastic only)
E
Series
DBSXX
09, 15, 25, 37, 50
F
RoHS compliant
Rev.
Description
Date
Material/Color
XX
ZM=Zinc diecast
PG=Plastic gray
PB=Plastic black
PT=Plastic tan
AM=Aluminum diecast metal
PC=Plastic chrome plated
Style
X
[blank]=V (oval entry)
U=U style (round entry)
E=Ethernet
R=Right-angle
F
Approved
Drawing
Name
Approved Howard
Checked Lizzy
Drawn Tina
0.0 ± 0.35
Date
08/10/99
08/10/99
08/10/99 Part No.:
Central Components Manufacturing
440 Lincoln Blvd., Middlesex, New Jersey 08846
Phone 732 469-5720 888 288-5152 Fax 732 469-1919
G
DBSXX-ZM-X-XX-XX-XX
7
8
9
0.00 ± 0.20 Angles ± 3’
UNIT: mm
5
6
Description: Metal D-sub backshell
