ALUMINUM ELECTROLYTIC CAPACITORS
KS
Snap-in Terminal Type, For Audio Equipment,
Smaller-sized
series
Smaller and high-tone quality than KG series TYPE-
1
grade.
An effect to tone quallity improvement by replacement from
a small standard product to use.
Compliant to the RoHS directive (2011/65/EU).
KG
TYPE -1
Smaller
KS
Specifications
Item
Category Temperature Range
Rated Voltage Range
Rated Capacitance Range
Capacitance Tolerance
Leakage Current
Tangent of loss angle (tan
δ)
–
40 to +85°C
Performance Characteristics
25 to 100V
680 to 33000µF
± 20% at 120Hz, 20°C
After 5 minutes' application of rated voltage, leakage current is not more than 3 CV (µA),
[C : Rated Capacitance(µF), V : Voltage ( V ) ]
For capacitance of more than 22000µF, add 0.02 for every increase of 1000µF.
Rated voltage(V)
tan
δ
(MAX.)
Measurement frequency : 120Hz at 20°C
25 to 71
0.30
80
•
100
0.25
25 to 100
4
12
Capacitance change
tan
δ
Leakage current
Measurement frequency : 120Hz
Rated voltage(V)
Stability at Low Temperature
Impedance ratio ZT/Z20(MAX.)
Z
–
25°C/ Z+20°C
Z
–
40°C/ Z+20°C
Endurance
The specifications listed at right shall be met when the
capacitors are restored to 20°C after the rated voltage is
applied for 1000 hours at 85°C.
Within ±20% of the initial value
200% or less than the initial specified value
Less than or equal to the initial specified value
Shelf Life
Marking
After storing the capacitors under no load at 85°C for 1000 hours and then performing voltage treatment based on JIS C 5101-4 clause
4.1 at 20°C, they shall meet the specified values for the endurance characteristics listed above.
Printed with silver color letter on black sleeve.
Drawing
Sleeve (P.E.T.)
Type numbering system (Example : 35 V 8200µF)
1
2
3
4
5
6
7
8
9 10 11
12
Polarity bar
L K S 1 V 8 2 2 ME S A
φ
D
+1MAX.
Case dia.code
Configuration
L
±
2
10
6.3±1
Capacitance tolerance (±20%)
Rated capacitance (8200
µ
F)
Rated voltage (35V)
Series name
Pressure relief vent
φD
20
22
25
30
35
Code
Y
Z
A
B
C
0.8
- 0.1
+0.2
Type
10
±
0
.1
0
6.3
±1
3.5
.2
+ 0 .1
.8
- 0
2-2φ
±
0.1
(PC board hole dimensions)
1.5
+0.2
- 0.1
(Terminal dimensions)
Dimension table in next page.
CAT.8100C
