5-1470380-0 Product Details
Live Product Chat
Product View
2mm AMPMODU
5 of 6 EU R oHS/ELV C om plia nt
(
Find R oHS C om plia nt
Alte rna te s
/
Sta te m e nt of C om plia nce
)
Quick Links
C heck Pricing & Availability
Search for Tooling
View Mating Products (12)
Product Feature Selector
C ontact Us About This Product
5-1470380-0
T E I nternal N umber: 5 - 1 4 7 0 3 8 0 - 0
Product Highlights:
l
Receptacle
l
PC B Mount Style = Surface Mount
l
Not Shrouded
l
Number of Positions = 50
l
No PC B Retention Feature
View all Features
A dd to M y P art L is t
Reques t Sample
Find Similar P roduc ts
Pending Obsolescence
C ontact Product Information C enter
Buy P roduc t
Documentation & Additional Information
Product Drawings:
l
None Available
Catalog Pages/Data Sheets:
l
None Available
Product Specifications:
l
BOX HEADER, 2.0MM PITC H, SMT TYPE.
(PDF, English)
Application Specifications:
l
None Available
Instruction Sheets:
l
None Available
CAD Files:
l
None Available
List all Documents
Product Features
(Please use the Product Drawing for all design activity)
Product Type Features:
l
Product Type
= Receptacle
l
PC B Mount Style
= Surface Mount
l
Shrouded
= No
l
Number of Positions
= 50
l
PC B Retention Feature = No
l
PC B Mount Angle
= Right Angle
l
Keyed
= No
l
Holddown Feature
= Without
l
Post Size (mm [in]) = 0.50 [.020]
Electrical Characteristics:
l
Voltage (VAC ) = 250
l
C ontact C urrent Rating (Amps.) = 1
l
Insulation Resistance (M?) = 5,000
Termination Related Features:
l
Solder Tail C ontact Plating = Tin-Lead (90) over Nickel (50)
Body Related Features:
l
Selectively Loaded
= No
l
Post Number(s) Omitted
= None
l
C enterline, Matrix (mm [in]) = 2.00 x 2.00 [.079 x .079]
l
Mating Pin-to-PC B Dimension (mm [in]) = 2.00 [0.079]
l
Mount Type = Printed C ircuit Board
l
Number of Rows = Dual
l
UL Rating = UL 94V-0
Contact Related Features:
l
C ontact Mating Area Plating Material
= Gold (8)
l
C ontact Base Material = C opper Alloy
l
Approved Standards = UL E28476, C SA LR7189
Housing Related Features:
l
Housing Material = High Temperature Thermoplastic
l
Dielectric Strength (VAC ) = 650
l
Housing Flammability Rating = UL 94V-0
l
Housing C olor = Black
l
Housing Entry Style = C losed Top
Industry Standards:
l
RoHS/ELV C ompliance
= ELV compliant, 5 of 6 C ompliant
l
Lead Free Solder Processes
= Wave solder capable to 240?C
Conditions for Usage:
l
Temperature Range (?C ) = -40 – +105
Packaging Related Features:
l
Packaging Method
= Tape Mounted on Reel
Other:
l
Brand = AMP
Additional Information:
l
Product Line Information
Related Products:
l
Tooling
l
Mating Products (12)
