97-Series General Oscillator Specifications
Description
Frequency Range
Overall Stability (+/-)
Supply Voltage
Operating Temperature Range
Capacitive Load on Output
TTL Load on Output
Supply Current:
5V 0.5-23.9MHz
5V 24-49.9MHz
5V 50-69.9MHz
5V 70-125MHz
3.3V 0.5-23.9MHz
3.3V 24-49.9MHz
3.3V 50-69.9MHz
3.3V 70-125MHz
Output Voltage :
High (5Vdd)
High (3.3Vdd)
Low (5Vdd)
Low (3.3Vdd)
Symmetry
Jitter
Rise/Fall time (frequency dependant)
Start up Time
Min
0.5
10
3.3
0~70
15
1
Typ
Max
125
100
5
-55~125
50
10
20
30
40
60
15
20
30
45
4.5
2.4
0.5
0.5
48:52
10
10
Unit
MHz
ppm
V
Deg C
pF
TTL
mA
mA
mA
mA
mA
mA
mA
mA
V
V
V
V
%
pS
nS
mS
Pin Assignments
Pin 1
N/C (9700) or Tri-State (9710)
Pin 7
Ground
Pin 8
Output
Pin 14
+V DC
Tri-State Voltages
N.C
Output Active
>2.2V
Output Active
<0.8V
Output Disabled
(Pin 1 has internal pull up resistor to allow
it to float High)
40:60
1
45:55
1
8
Options and How to Specify
AEL97
Pin 1:
0=N.C., 1=E/D
Supply voltage:
0=5V, 3=3.3V
Stability* (+/-ppm):
C=100, B=50, A=25
Temperature range:
S=0~+70, I=-40~+85C, M=-55+125C
e.g. AEL9703CI 20MHz = N.C, 3.3V, +/-100ppm, -40~+85C, 20MHz
Module "D", Airtech II
Jenner Road, Manor Royal
Crawley RH10 9GA
AEL Crystals Ltd. Reserve the right to amend specifications without notification. Please ensure you have the latest issue
*please contact our Sales Office for further options
TITLE
Part Number
Stock Number
Issue Date
Issue Number
AEL 97-series oscillator
Contact Sales Office
Contact Sales Office
16/03/2006
1
Not to be reproduced without permission of AEL Crystals Ltd
