g
MODEL
PRESSURE SENSOR
SP SERIES
FEATURES
The SP series is an inexpensive plastic package type.
•
SP20 is a DIP type.
•
SP30 is a FP and SIP type.
•
These units correspond to regular equipment, measurement equipment, home electronic equipment,
medical equipment and others.
SP20C-G102
U
Terminal direction
Rated pressure
MODEL
SP30C-A102
F
No mark: SIP type
F: FP type
Pressure type
Rated pressure
A: Absolute pressure
G: Gauge pressure
Pressure type
G: Gauge pressure
SPECIFICATIONS
Model No.
Rated pressure
Pressure type
Pressure medium
Excitation current
Maximum overload pressure
Temperature range
Full scale voltage
Offset voltage
Bridge resistance
Offset voltage temperature
characteristics *1
Full scale voltage temperature
characteristics *1
Linearity
mA
kgf/cm
2
°C
mV
mV
KΩ
%FS/°C
%FS/°C
%FS
±0.5
±0.2
±1.5
0±2.5
5+1
+0.1
+0.05
+0.3
1.5
Rated pressure x 3
-20~100
60~140
0+20
kgf/cm
2
SP20C-G
101
+0.1
201
+0.2
501
+0.5
102
+1.0
Gauge pressure
Non-Corrosive gases
1.0
Rated pressure x 1.5
SP30C-A(G)
202
-1.0~2.0
502
-1.0~5.0
103
-1.0~10
501
+0.5
102
+1.0
Gauge-Absolute pressure
Anti Corrosive Air
1.0
Rated pressure x 2
-20~80
60~140
0+20
5+1
+0.1
+0.05
+0.3
NOTE
*I The temperature range is 0°C to 60°C. If there is no specification, the temperature range is 25°±5°C. These specifications are examples. Please contact us for other specifications.
EXTERNAL FIGURE AND TERMINAL ARRANGEMENT
SP20
SP30
FP type
SIP type
Unit: mm
