Product:
8049
Magnet Wire, #18 Sol BC, PUR/NYL Ins
Product Description
Magnet Wire, 18AWG (Solid) Bare Copper, PUR/NYL Insulation, J-W-1177/9 MW 28-C
Technical Specifications
Product Overview
Suitable Applications:
solderable magnet wire
Physical Characteristics (Overall)
Conductor
AWG Stranding
18
Solid
Material
No. of Conductors
BC - Bare Copper 1
1
Conductor Count:
Insulation
Material
Nominal Diameter Nominal Wall Thickness
0.001 in
PUR/Nylon - Polyurethane + Nylon 0.0424 in
Outer Jacket
Max. Diameter
0.0424 mm
Construction and Dimensions
Min Increase in OD:
0.001 in
Electrical Characteristics
Conductor DCR
Nominal Conductor DCR
6.4 Ohm/1000ft
Current
Max. Recommended Current [A]
Single conductor in free air @ 30ºC: 2.3 A
Voltage
Breakdown Voltage
2850 V Minimum (at Room Temperature)
Temperature Range
Non-UL Temp Rating:
130°C
Mechanical Characteristics
Approximate Length:
Turns Per Linear Inch:
100 ft
23.9
Turns Per Square Inch:
Bulk Cable Weight:
Min. Bend Radius/Minor Axis:
571
5 lbs/1000ft
0.17 in
Standards
Military Compliance:
Other Specification:
J-W-1177/9
NEMA-MW28-C (Single)
Applicable Environmental and Other Programs
EU Directive 2000/53/EC (ELV):
EU Directive 2003/96/EC (BFR):
EU Directive 2011/65/EU (RoHS 2):
EU Directive 2012/19/EU (WEEE):
Yes
Yes
Yes
Yes
EU Directive 2015/863/EU (RoHS 2 amendment): Yes
EU Directive Compliance:
EU CE Mark:
CA Prop 65:
MII Order #39 (China RoHS):
EU Directive 2003/11/EC (BFR)
Yes
Yes
Yes
Flammability, LS0H, Toxicity Testing
UL voltage rating:
N/A
Plenum/Non-Plenum
Plenum (Y/N):
No
Part Number
Variants
Item # Color Put-Up Type Length
8049
None
Reel
1 ft
UPC
612825194453
History
Update and Revision:
Revision Number: 0.372 Revision Date: 08-27-2021
