Product:
8058
Magnet Wire, #36 Sol BC, PUR/NYL Ins
Product Description
Magnet Wire, 36AWG (Solid) Bare Copper, PUR/NYL Insulation, J-W-1177/9 MW 28-C
Technical Specifications
Product Overview
Suitable Applications:
solderable magnet wire
Physical Characteristics (Overall)
Conductor
AWG Stranding
36
Solid
Material
No. of Conductors
BC - Bare Copper 1
1
Conductor Count:
Insulation
Material
Nominal Diameter Nominal Wall Thickness
0.0004 in
PUR/Nylon - Polyurethane + Nylon 0.0058 in
Outer Jacket
Max. Diameter
0.0058 mm
Construction and Dimensions
Min Increase in OD:
0 in
Electrical Characteristics
Conductor DCR
Nominal Conductor DCR
414.8 Ohm/1000ft
Current
Max. Recommended Current [A]
Single conductor in free air @ 30ºC: 0.036 A
Voltage
Breakdown Voltage
1075 V Minimum (at Room Temperature)
Temperature Range
Non-UL Temp Rating:
130°C
Mechanical Characteristics
Approximate Length:
Turns Per Linear Inch:
6400 ft
180
Turns Per Square Inch:
Bulk Cable Weight:
Min. Bend Radius/Minor Axis:
32400
0.079 lbs/1000ft
0.03 in
Standards
Military Compliance:
Other Specification:
J-W-1177/9
NEMA-MW-C (Single)
Applicable Environmental and Other Programs
EU Directive 2000/53/EC (ELV):
EU Directive 2003/96/EC (BFR):
EU Directive 2011/65/EU (RoHS 2):
EU Directive 2012/19/EU (WEEE):
Yes
Yes
Yes
Yes
EU Directive 2015/863/EU (RoHS 2 amendment): Yes
EU Directive Compliance:
EU CE Mark:
CA Prop 65:
MII Order #39 (China RoHS):
EU Directive 2003/11/EC (BFR)
Yes
Yes
Yes
Flammability, LS0H, Toxicity Testing
UL voltage rating:
N/A
Plenum/Non-Plenum
Plenum (Y/N):
No
Part Number
Variants
Item # Color Put-Up Type Length
8058
None
Reel
1 ft
UPC
612825194545
History
Update and Revision:
Revision Number: 0.369 Revision Date: 08-27-2021
© 2021 Belden, Inc
All Rights Reserved.
Although Belden makes every reasonable effort to ensure their accuracy at the time of this publication, information and specifications described here in are subject to error or omission and to change without
notice, and the listing of such information and specifications does not ensure product availability.
Belden provides the information and specifications herein on an "ASIS" basis, with no representations or warranties, whether express, statutory or implied. In no event will Belden be liable for any damages
(including consequential, indirect, incidental, special, punitive, or exemplary damages) whatsoever, even if Belden has been advised of the possibility of such damages, whether in an action under contract,
negligence or any other theory, arising out of or in connection with the use, or inability to use, the information or specifications described herein.
All sales of Belden products are subject to Belden's standard terms and conditions of sale.
Belden believes this product to be in compliance with all applicable environmental programs as listed in the data sheet. The information provided is correct to the best of Belden's knowledge, information and belief
at the date of its publication. This information is designed only as a general guide for the safe handling, storage, and any other operation of the product itself or the one that it becomes a part of. The Product
Disclosure is not to be considered a warranty or quality specification. Regulatory information is for guidance purposes only. Product users are responsible for determining the applicability of legislation and
regulations based on their individual usage of the product.
