352046-1 Product Details
Live Product Chat
Product Photo
2mm Hard Metric PCB Mount Connectors (Z-PACK 2mm HM)
Always ELV C om plia nt
(
Sta te m e nt of C om plia nce
)
Quick Links
C heck Pricing & Availability
Search for Tooling
Product Feature Selector
C ontact Us About This Product
352046-1
T E I nternal N umber: 3 5 2 0 4 6 - 1
Product Highlights:
l
C onnector
l
C onnector Type = Type M
l
Plug
l
Interface Type = 2mm HM
l
C ontact Type = AC TION PIN Post, Signal
View all Features
Obsolete
C ontact Product Information C enter
A dd to M y P art L is t
Reques t Sample
Find Similar P roduc ts
Buy P roduc t
Documentation & Additional Information
Product Drawings:
l
None Available
Catalog Pages/Data Sheets:
l
None Available
Product Specifications:
l
None Available
Application Specifications:
l
None Available
Instruction Sheets:
l
None Available
CAD Files:
l
None Available
Additional Information:
l
Product Line Information
Related Products:
l
Tooling
Product Features
(Please use the Product Drawing for all design activity)
Product Type Features:
l
Product Type
= C onnector
l
C onnector Type
= Type M
l
Gender
= Plug
l
Number of Positions
= 77
l
PC B Mount Angle
= Vertical
l
Mating Polarization
= Without
l
Shielded
= No
Mechanical Attachment:
l
Board Mount
= Free Board
l
Module Length (mm [in]) = 49.88 [1.965]
l
C rosstalk Version
= Standard
Termination Related Features:
l
Interface Type
= 2mm HM
l
Termination End Plating = Tin-Lead over Nickel
Body Related Features:
l
Number of Rows
= 5+2
l
Grounding C ontact
= Without
l
Rows Loaded = A, D, F, Z, E, C , B
Contact Related Features:
l
C ontact Type = AC TION PIN Post, Signal
l
Feedthrough Post Length (mm [in])
= 13.00 [0.512]
l
C ompactPC I
= No
l
C ontact Mating Area Plating Material
= Gold (30)
l
C ontact Base Material = Phosphor Bronze
Housing Related Features:
l
Housing Material = Polyester GF
l
Housing C olor = Gray
Industry Standards:
l
RoHS/ELV C ompliance
= ELV compliant
l
Lead Free Solder Processes
= Not suitable for lead free processing
l
RoHS/ELV C ompliance History = Always was ELV compliant
Other:
l
Brand = AMP
