SMD Multi Volt™ Crystal Oscillator
The ECS-2520SMV is a miniature SMD HCMOS Oscillator with Multi
Tight Stability
Volt™ capability of 1.62 ~ 3.63 V with a tight stability of ±5 or ±10
ppm. The 2.5 x 2.0 x 1.0 mm ceramic package is ideal for Low
Power/Portable, Industrial and IOT. applications.
ECS-2520SMV SMD XO
Request a Sample
ECS-2520SMV
OPERATING CONDITIONS / ELECTRICAL CHARACTERISTICS
PARAMETERS
Frequency Range
* Frequency Stability
Supply Voltage
Output Load
Output voltage Level
Rise & Fall time
Start Up Time
Phase Jitter
Duty Cycle
Input Current
(No Load)
Standby Current
Operating Temp*
Storage Temp
CONDITIONS
MIN
ECS-2520SMV
TYP
MAX
UNITS
•
•
•
•
•
•
•
2.5 x 2.0 mm Footprint
Extended Temp Range
RoHS Compliant
Wide Supply Voltage
Tight Stability
Compatible with 1.8V, 2.5V or
3.3V Power Supply
60.000
MHz
-40 ~ +105°C (FP Opt)
±10
ppm
1.62
3.63
V
CMOS
15
pF
V
OL:
0.2 V
dd
max./V
OH:
0.8V
dd
min.V DC
20%V
dd
–
80%V
dd
3
nS
10
mS
12 KHz to 20 MHz
1
pS
@ ½ V
dd
45/55
%
6
P Option
-40
-55
10
10
+105
+125
mA
µA
°C
°C
8.000
DIMENSIONS (mm)
PAD CONNECTIONS
1
Tri-state
2
Gnd
3
Output
4
Vdd
Tri State Function
Pin 1
Output
0.7 * Vdd
Min
or
NC
Active
0.3 * Vdd
Max.
High Impedance
Figure 2)
Suggested Land Pattern
Figure 1)
Top, Side, and Bottom views
PART NUMBERING GUIDE: Example ECS-2520SMV-250-FP-TR
ECS
-
SERIES
2520SMV
2.5 x 2.0 mm
Multi Volt Oscillator
Tight Stability
FREQUENCY
ABBREVIATION
250 = 25.000 MHz
See Developed
Frequencies Pg.2
-
* STABILITY
F= ±10 ppm
G = ±5 ppm
TEMP RANGE -
N = -40 ~ +85°C
P = -40 ~ +105°C
PACKAGING
-TR =
Tape
& Reel
1K/Reel
* Frequency Stability includes initial tolerance, temperature, supply voltage & load change reflow frequency shift, and aging.
Rev.2019
