ARC1
Planar (Flat) Leaded Resistor
This versatile Non Inductive quality range of high voltage thick film resistors, available
in conformal or glass coatings, has been designed into a wide range of applications
including high voltage medical test equipment, HV power supplies and various high
spec instrumentation.
•
Variety of configurations
•
High voltage capability
•
RoHS Compliant
•
Low TCR
•
Tolerance as low as ± 0.1%
•
Non inductive
•
Both axial and radial leaded
Electrical Specifications
Electrical data
Type
ARC1-325
ARC1-338
ARC1-513
ARC1-551
ARC1-1025
ARC1-1051
ARC1-1538
ARC1-1551
ARC1-1576
ARC1-2599
P
Watt
1
1.5
1
2
2
3
3
4.5
5.5
10
U
kVdc
8
10
5
20
10
30
15
30
35
35
± 0.1 - 10%
15 ppm/°C
50K - 25M
100K - 30M
50K - 50M
100K - 200M
100K - 200M
300K - 300M
300K - 300M
400K - 300M
600K - 300M
2M - 300M
Resistance range available at Tolerance / TCR
± 0.1 - 10%
25 ppm/°C
10K - 50M
20K - 60M
10K - 100M
30K - 250M
25K - 300M
50K - 300M
60K - 300M
75K - 300M
120K - 300M
200K - 300M
± 0.25 - 10%
50 ppm/°C
4K - 200M
8K - 250M
1K - 150M
4K - 400M
4K - 300M
8K - 500M
9K - 500M
12K - 500M
18K - 500M
30K - 500M
± 0.5 - 10%
100 ppm/°C
4K - 1G
8K - 1G
200R - 250M
1K - 1G
1K - 1G
3K - 1G
3K - 1G
4K - 1G
6K - 1G
12K - 1G
± 1 - 10%
200 ppm/°C
4K - 1G
8K - 1G
100R - 1G
300R - 1G
400R - 1G
800R - 1G
800R - 1G
1K - 1G
1K - 1G
3K - 1G
± 5 - 10%
200 ppm/°C
4K - 4G
8K - 4G
50R - 10G
200R - 25G
200R - 30G
400R - 30G
500R - 30G
600R - 30G
1K - 30G
3K - 30G
Characteristics
Operating temperature:
Tolerance (Code):
Temperature coefficient (Code):
Insulation resistance:
Dielectric strength:
Thermal shock:
Overload:
Moisture resistance:
-55°C to +175°C
± 0.1% (B), ± 0.25% (C), ± 0.5% (D), ± 1% (F), ± 2% (G), ± 5% (J), ± 10% (K)
± 15ppm/°C (A), ± 25ppm/°C (E), ± 50ppm/°C (F), ± 100ppm/°C (S), ± 200ppm/°C (L)
TCR stated is measured at +25˚C and +85˚C. For TCR outside this range, please contact ARCOL
> 10,000Mohm
> 1000 Volt
R/R
0.2% max
R/R
0.25% max
R/R
0.25% max
1.5 x Pnom, 5 sec (do not exceed 1.5 x V max)
500 Volts @ 25°C, 75% relative humidity
25°C, 75% relative humidity
Load life:
R/R
0.25% max 1000 hours at rated power
These resistors are tailored for operation in air and not aggresive atmospheres.
For special applications (i.e. oil, casting, moulding, etc) please contact ARCOL.
ARCOL UK Limited,
Threemilestone Ind. Estate,
Truro, Cornwall, TR4 9LG, UK.
T +44 (0) 1872 277431
F +44 (0) 1872 222002
E sales@arcolresistors.com
The information contained herein does not form part of
a contract and is subject to change without notice. Arcol
operate a policy of continual product development, therefore,
specifications may change.
It is the responsibility of the customer to ensure that the
component selected from our range is suitable for the intended
application. If in doubt please ask Arcol.
Page 1 of 2
5/11-38
www.arcolresistors.com
ARC1
Planar (Flat) Leaded Resistor
Ordering Procedure
Standard Resistor To specify standard: Series, Termination
Temperature Coefficient Code, e.g.: ARC1-551 AU 1G D E
Termination Style (Code) Axial (A), Radial (R)
Coating Type (Code) Conformal (U), Glass (G)
Tolerance (Code) ±0.1% (B), ±0.25% (C), ±0.5% (D), ±1% (F),
±2% (G), ±5% (J), ±10% (K)
Temperature Coefficient (Code) ±15ppm/°C (A), ±25ppm/°C (E),
±50ppm/°C (F), ±100ppm/°C (S), ±200ppm/°C (L)
Style, Coating Type, Ohmic Value, Tolerance Code and
Derating Curve
100
Percent Rated Power
80
60
40
20
p
0
0
40
100
Temperature ˚C
°C
Tem erature
175
Dimensions (mm)
36±3*
L
2.5
L
2.5
AXIAL = A
Ø0.8*
RADIAL = R
B
Ø0.8*
Dimensions
Type
ARC1-325
ARC1-338
ARC1-513
ARC1-551
ARC1-1025
ARC1-1051
ARC1-1538
ARC1-1551
ARC1-1576
ARC1-2599
L
25.4
38.0
12.7
50.8
25.4
50.8
38.0
50.8
76.2
101.6
B
3.8
3.8
5.0
5.0
10.0
10.0
15.0
15.0
15.0
24.0
R
*ARC1-513
Pins: L = 9±1
*967.5.13
Ø = 0.6 x 0.3
R
30±5*
22.9
35.7
10.2
48.3
22.9
48.3
35.7
48.3
73.4
98.6
ARCOL UK Limited,
Threemilestone Ind. Estate,
Truro, Cornwall, TR4 9LG, UK.
T +44 (0) 1872 277431
F +44 (0) 1872 222002
E sales@arcolresistors.com
The information contained herein does not form part of
a contract and is subject to change without notice. Arcol
operate a policy of continual product development, therefore,
specifications may change.
It is the responsibility of the customer to ensure that the
component selected from our range is suitable for the intended
application. If in doubt please ask Arcol.
Page 2 of 2
5/11.38
www.arcolresistors.com
