Z iL O G
The ZiLOG Family of Serial
Communication Controllers
Setting the standards for SCCs
Over the last 20 years ZiLOG has set the standard for
SCCs. Built from the industry acclaimed Serial
Communication Controller core, ZiLOG offers a wide
selection of (SCCs) based on your application require-
ments.
®
Reducing the need for external logic
ZiLOG’s SCCs offer low power consumption, higher per-
formance, and superior noise immunity. The many
on-chip features offered in our SCCs help dramatically to
reduce the need for external logic found with much of the
competition. Go with an SCC you can trust, and make
ZiLOG your one-stop SCC solution provider.
• Ability to accommodate a crystal oscillator,
baud rate generator, and digital phase-locked
loop on each channel
• Processing speeds up to 5 Mbps
• Multi-protocol format (async, monosync,
bisync, SDLC/HDLC, SDLC/HDLC loop)
• Encodes in the following modes: NRZI, FM0,
FM1, and Manchester
• CRC-16 or CRC-CCITT error detection
• 4-byte transmit FIF0/8-byte receive FIF0
Offering a fully integrated solution
The standard serial and integrated communications con-
trollers, Z85C30 and Z16C35, allow you to easily imple-
ment a fully integrated solution for many networking
applications. The chips’ features include:
• Dual full-duplex channels
• Ability to accommodate a crystal oscillator, baud
rate generator, and digital phase-locked
loop on each channel
• Processing speeds up to 4 Mbps
• Multi-protocol format (async, monosync,
bisync, SDLC/HDLC, SDLC/HDLC loop)
• Encodes in the following modes: NRZ, NRZI,
FM0, FM1, and Manchester
• CRC-16 or CRC-CCITT error detection
• 1-byte transmit FIF0/3-byte receive FIF0
• 2 transmit and 2 receive DMA channels (16C35 only)
Increasing speed
The standard and integrated universal serial con-
trollers Z16C30, Z16C35, and Z16C32 offer faster
performance. Features include:
• Dual full-duplex channels (Z16C30)
• Single full-duplex channel (Z16C32)
• Accommodates two baud rate generators
and one digital phase-locked loop
(on each channel)
• 2 DMA control signals per channel
(Z80C30/Z85C30 only)
(Continued on back side)
Simplifying software
The enhanced dual and mono SCCs Z80230, Z85230, and
Z85233, include many features that make programming
easy. These parts also reduce CPU overhead, allowing the
programmer to select packet handling response and
improve cycle access recovery time. Features include:
• Dual full-duplex channels (Z80230/Z85230)
• Single full-duplex channel (Z85233 only)
ZiLOG SCC Solutions
Standard and integrated universal serial controllers
Z16C30/Z16C32
(Continued)
• Processing speeds up to 10 Mbps (Z16C30)
• Processing speeds up to 20 Mbps (Z16C32)
• Multi-protocol format (async, monosync, slaved
monosync, bisync, isochronous, nine-bit, SDLC/HDLC, SDLC/HDLC loop)
• Encodes in the following modes: NRZ, NRZI-Mark,
NRZI-Space, Bi-Phase-Mark (FM1), Bi-Phase-Space
(FM0), Bi-Phase-Level (Manchester), Differential Bi-Phase-Level
• CRC-32, CRC-16, and CRC-CCITT
• 32-byte transmit FIF0/32-byte receive FIF0
• 2 DMA control signals per channel (16C30 only)
• Transmit and receive DMA controllers with single
buffer, pipelined, array, and linked-list modes (16C32 only)
Serial
Family
Channels
DMA
Controllers
Bus Interface
MHz
Part number
Package
Pins
Op. Temp. (
o
C)
SCC
2
0
Multiplex
8
10
Nonmultiplex
8
10
16
ISCC
ESCC
2
2
2
0
Multiplex and
nonmultiplex
Multiplex
10
16
10
16
Nonmultiplex
8
10
16
20
EMSCC
1
0
Nonmultiplex
10
16
20
10
USC
2
0
Multiplex and
nonmultiplex
IUSC
1
2
Multiplex and
nonmultiplex
20
Z80C3008PEC
Z80C3008PSC
Z80C3008VSC
Z80C3010PSC
Z80C3010VSC
Z85C3008PEC
Z85C3008PSC
Z85C3008VEC
Z85C3008VSC
Z85C3010PEC
Z85C3010PSC
Z85C3010VEC
Z85C3010VSC
Z85C3016PSC
Z85C3016VEC
Z85C3016VSC
Z16C3510VSC
Z16C3516VSC
Z8023010PSC
Z8023010VSC
Z8023016PSC
Z8023016VSC
Z8523008PEC
Z8523008PSC
Z8523008VEC
Z8523008VSC
Z8523010PEC
Z8523010PSC
Z8523010VEC
Z8523010VSC
Z8523016PEC
Z8523016PSC
Z8523016VEC
Z8523016VSC
Z8523020PSC
Z8523020VSC
Z8523310FSC
Z8523310VSC
Z8523316FSC
Z8523316VSC
Z8523320FSC
Z16C3010AEC
Z16C3010ASC
Z16C3010VEC
Z16C3010VSC
Z16C3220FSC
Z16C3220VSC
DIP
PLCC
DIP
PLCC
DIP
PLCC
DIP
PLCC
DIP
PLCC
PLCC
DIP
PLCC
DIP
PLCC
DIP
PLCC
DIP
PLCC
DIP
PLCC
DIP
PLCC
PQFP
PLCC
PQFP
PLCC
PQFP
VQFP
PLCC
PQFP
PLCC
40
44
40
44
40
44
40
44
40
44
68
40
44
40
44
40
44
40
44
40
44
40
44
44
-40 -100
0 -70
-40
0
-40
0
-40
0
-40
0
-100
-70
-100
-70
-100
-70
-100
-70
-40 -100
0 -70
0 -70
0
-70
-40
0
-40
0
-40
0
-40
0
-40
0
-40
0
-100
-70
-100
-70
-100
-70
-100
-70
-100
-70
-100
-70
0
-70
100
68
80
68
-40 -100
0 -70
-40 -100
0 -70
0 -70
FLY-Z0SCCFAM-0100
www.
zilog
.com • Worldwide Customer Support Center 877-945-6427 (Toll Free US and Canada)
