BC847 series
Rev. 12 — 24 October 2019
45 V, 100 mA NPN general-purpose transistors
Product data sheet
1. Product profile
1.1. General description
NPN general-purpose transistors in a small SOT23 (TO-236AB), very small SOT323 (SC-70) or
ultra small SOT883 (DFN1006-3) Surface-Mounted Device (SMD) plastic package.
Table 1. Product overview
Type number[1] Package
Nexperia
BC847
BC847A
BC847B
BC847C
BC847W
BC847AW
BC847BW
BC847CW
BC847AM
BC847BM
BC847CM
[1]
Valid for all available selection groups.
PNP complement
JEITA
-
JEDEC
TO-236AB
BC857
BC857A
BC857B
BC857C
SOT23
SOT323
SC-70
-
BC857W
BC857AW
BC857BW
BC857CW
SOT883
SC-101
-
BC857AM
BC857BM
BC857CM
1.2. Features and benefits
•
•
•
•
General-purpose transistors
SMD plastic packages
Three different gain selections
AEC-Q101 qualified
1.3. Applications
•
General-purpose switching and amplification
Nexperia
BC847 series
45 V, 100 mA NPN general-purpose transistors
1.4. Quick reference data
Table 2. Quick reference data
T
amb
= 25 °C unless otherwise specified.
Symbol
V
CEO
I
C
h
FE
Parameter
collector-emitter voltage
collector current
DC current gain
h
FE
group A
h
FE
group B
h
FE
group C
V
CE
= 5 V;
I
C
= 2 mA
Conditions Min
open base
-
-
110
110
200
420
Typ
-
-
-
180
290
520
Max
45
100
800
220
450
800
Unit
V
mA
2. Pinning information
Table 3. Pinning information
Pin
Symbol
SOT23; SOT323
1
2
3
B
E
C
base
emitter
collector
1
2
3
B
E
sym123
Descrition
Simlified outline
Graphic symbol
C
SOT883
1
2
3
B
E
C
base
emitter
collector
1
2
Transparent
top view
C
3
B
E
sym123
BC847_SER
All information provided in this document is subject to legal disclaimers.
©
Nexperia B.V. 2019. All rights reserved
Product data sheet
Rev. 12 — 24 October 2019
2 / 17
Nexperia
BC847 series
45 V, 100 mA NPN general-purpose transistors
3. Ordering information
Table 4. Ordering information
Type number
Package
Name
BC847
BC847A
BC847B
BC847C
BC847W
BC847AW
BC847BW
BC847CW
BC847AM
BC847BM
BC847CM
SC-101
lesdless ultra small plastic package;
3 solder lands; body 1.0 x 0.6 x 0.5 mm
SOT 883
SC-70
SOT323
TO-236AB
Description
plastic surface-mounted package; 3
leads
Version
SOT23
4. Marking
Table 5. Marking codes
Type number
BC847
BC847A
BC847B
BC847C
BC847W
BC847AW
BC847BW
BC847CW
BC847AM
BC847BM
BC847CM
[1]
% = placeholder for manufacturing site code
Marking code
[1]
[1]
[1]
[1]
[1]
[1]
[1]
[1]
1H%
1E%
1F%
1G%
1H%
1E%
1F%
1G%
D4
D5
D6
BC847_SER
All information provided in this document is subject to legal disclaimers.
©
Nexperia B.V. 2019. All rights reserved
Product data sheet
Rev. 12 — 24 October 2019
3 / 17
Nexperia
BC847 series
45 V, 100 mA NPN general-purpose transistors
5. Limiting values
Table 6. Limiting values
In accordance with the Absolute Maximum Rating System (IEC 60134).
Symbol
V
CBO
V
CEO
V
EBO
I
C
I
CM
I
BM
P
tot
Parameter
collector-base voltage
collector-emitter voltage
emitter-base voltage
collector current
peak collector current
peak base current
total power dissipation
SOT23
SOT323
SOT883
T
j
T
amb
T
stg
[1]
[2]
Conditions
open emitter
open base
open collector
single pulse; t
p ≤ 1 ms
single pulse; t
p ≤ 1 ms
T
amb
≤ 25 °C
Min
-
-
-
-
-
-
[1]
-
[1]
-
[2]
-
-
-65
-65
Max
50
45
6
100
200
100
250
200
250
150
150
150
Unit
V
V
V
mA
mA
mA
mW
mW
mW
°C
°C
°C
junction temperature
ambient temperature
storage temperature
Device mounted on an FR4 Printed-Circuit-Board (PCB); single-sided copper; tin-plated and standard footprint.
Device mounted on an PCB with 60 μm copper strip line, standard footprint.
6. Thermal characteristics
Table 7. Thermal characteristics
Symbol
Parameter
R
th(j-a)
thermal resistance from
junction to ambient
SOT23
SOT323
SOT883
[1]
[2]
Device mounted on an FR4 PCB; single-sided copper; tin-plated and standard footprint.
Device mounted on an PCB with 60 μm copper strip line, standard footprint.
Conditions
in free air
Min
Typ
Max
Unit
[1]
-
[1]
-
[2]
-
-
-
-
500
625
500
K/W
K/W
K/W
BC847_SER
All information provided in this document is subject to legal disclaimers.
©
Nexperia B.V. 2019. All rights reserved
Product data sheet
Rev. 12 — 24 October 2019
4 / 17
Nexperia
BC847 series
45 V, 100 mA NPN general-purpose transistors
aaa-028968
10
3
duty cycle =
Z
th(j-a)
(K/W)
10
2
1
0.5
0.2
0.1
0.05
10
0.01
0
0.02
0.75
0.33
1
10
-5
10
-4
10
-3
10
-2
10
-1
1
10
10
2
t
p
(s)
10
3
FR4 PCB; single-sided copper; tin-plated and standard footprint
Fig. 1.
SOT23: Transient thermal impedance from junction to ambient as a function of pulse duration; typical
values
10
3
Z
th(j-a)
(K/W)
10
2
aaa-028969
duty cycle =
1
0.5
0.2
0.1
0.05
0.02
0.75
0.33
10
0.01
0
1
10
-5
10
-4
10
-3
10
-2
10
-1
1
10
10
2
t
p
(s)
10
3
FR4 PCB; single-sided copper; tin-plated and standard footprint
Fig. 2.
SOT323: Transient thermal impedance from junction to ambient as a function of pulse duration; typical
values
BC847_SER
All information provided in this document is subject to legal disclaimers.
©
Nexperia B.V. 2019. All rights reserved
Product data sheet
Rev. 12 — 24 October 2019
5 / 17
