Insert Magnetic/IC Card Reader
Compact Insert Reader with Magnetic
and IC Card Interface
s
Ideally suited for applications using
3S4YR-SGR
hybrid magnetic stripe and IC cards
s
Landing-style IC contact supports both
ISO and CP8 chip contact locations
s
Red and green LEDs for operation
status indication
s
Solenoid-controlled IC card release
mechanism
s
Configurations available to read on card
push or pull
s
TTL-compatible interface
Ordering Information
Magnetic Tracks Supported (R, R/W)
1
—
R
R
R
—
—
R
R
—
—
2
—
R
R
R
R
R
R
R
R
R
3
—
R
R
R
—
—
—
—
R
R
Center
—
—
—
—
—
—
—
—
—
—
JIS II
—
—
—
—
—
—
—
—
—
—
IC Contact
ISO 7816
ISO 7816
ISO 7816, CP8
—
ISO 7816
—
ISO 7816
—
ISO 7816
—
Interface
TTL
TTL
TTL
TTL
TTL
TTL
TTL
TTL
TTL
TTL
Mag Read
Direction
Solenoid Cover
—
Push
Push
Push/pull
Push
Push/pull
Push
Push/pull
Push
Push/pull
Yes
Yes
Yes
No
Yes
No
Yes
No
Yes
No
No
No
No
No
No
No
No
No
No
No
Cable
No
No
No
No
No
No
No
No
No
No
Color
Black
Black
Black
Black
Black
Black
Black
Black
Black
Black
Part Number
3S4YR-SGR0J
3S4YR-SGR1J
3S4YR-SGR1X
3S4YR-SGR1N
3S4YR-SGR4J
3S4YR-SGR4N
3S4YR-SGR6J
3S4YR-SGR6N
3S4YR-SGR7J
3S4YR-SGR7N
Note: Consult the
IC Card Basics
section of this catalog for IC contact descriptions.
3S4YR-SGR
s
TYPICAL APPLICATIONS
• Remote Terminals for Computers
• Credit Card Readers
• ID Card Checkers
• Electronic Locks
• Automatic Gate Machines
• POS Terminals
• ATMs
• Gas Pump Control
• Vending Machines
• Pre-Paid Systems
• Kiosks
3S4YR-SGR
Specifications
Part number
Recommended card type
Service life
Operating power supply
Card feed speed
Current consumption
Mounting location
Ambient temperature
Ambient humidity
Vibration
Shock
Dimensions
Weight
Operation
Magnetic card
IC card
Mag head
IC contact
3S4YR-SGR (except 0J)
ISO 7810 - 7813
ISO 7816/1-2
300,000 passes (preliminary)
500,000 passes (preliminary)
5 VDC
±
5%
100 to 800 mm/sec.
2.5 A max. (during solenoid release), 100 mA typ.
Indoors — away from wind, rain, sunlight, and dust
0° to 45°C (32° to 113°F)
30% to 85% RH without condensation and frost formation
10-150 Hz, single vibration width of 0.15 mm or on acceleration of 2 G (19.6 m/s
2
),
whichever is smaller
20 G (196 m/s
2
) in X, Y, and Z directions, respectively
126L x 76W x 30H mm
(4.96L x 2.99W x 1.18H in)
Approx. 100 g (3.5 oz)
126L x 76W x 25H mm
(4.96L x 2.99W x 0.98H in)
3S4YR-SGR0J
Engineering Data
s
I/O INFORMATION
5V
Output signal levels
V
OL
= 0.4 V at 5 mA
V
OH
= 2.8 at 0.1 mA
GND
2
3S4YR-SGR
s
I/O INFORMATION
3S4YR-SGR
7626-5002SC (3M:26 pin), MIL-C-83503A conformed.
Pin #
1
2
3
4
5
6
7
8
9
10
11
12
13
Signal
RDT1
RCL1
RDT2
RCL2
RDT3
RCL3
P1
P2
SLN
LED 1
LED 2
CLS
IGND
Input/Output
Output
Output
Output
Output
Output
Output
Output
Output
Input
Input
Input
Output
x
Description
Read data, track 1
Read clock, track 1
Read data, track 2
Read clock, track 2
Read data, track 3
Read clock, track 3
Card detection
Card insertion completed
Solenoid ON
LED1 (Red) ON
LED 2 (Green) ON
Magnetic card loading
IC contact C5
Pin #
14
15
16
17
18
19
20
21
22
23
24
25
26
Signal
IVCC
IVPP
IRST
IDATA
ICLK
IRFV2
IRFV1
5VS
5VS
5V
0V
0V
0V
Input/Output
x
x
x
x
x
x
x
—
—
—
—
—
—
3S4YR-SGR
Description
IC contact C1
IC contact C6
IC contact C2
IC contact C7
IC contact C3
IC contact C8
IC contact C4
Power for solenoid
Power for solenoid
Power for logic
Ground
Ground
Ground
x
= Direct IC Contact
Dimensions
Unit: mm (inch)
s
3S4YR-SGR (Except 0J)
Inserted card position
Ejected card position
4 (0.16)
7.5 max. (0.30)
40
(1.57)
16.5 (0.65)
3 (0.12)
IC Card
Magnetic stripe (back)
68
(2.68)
60
(2.36)
76
(2.99)
54.3
(2.14)
2.7
(0.11)
IC Contact (Front)
Insert
Magnetic head and chip contacts
are located on the opposite side
of the card.
Mag head
50 (1.97)
4-ø3.5
Connector
IC
contact
57 (2.24)
126 (4.96)
1
4-R
1.5 (0.06)
A
30 (1.18)
20
(0.78)
1 (0.04)
6 (0.24)
1
(0.04)
21 (0.83)
5
4.2
10 (0.20) (0.17)
(0.39)
A
27.5
(1.08)
4.5
(0.18)
9 (0.35)
8 (0.31)
R
2
Section A-A
2
(0.08)
39 (1.54)
58 (2.28)
3
3S4YR-SGR
s
3S4YR-SGR0J
Inserted card position
Ejected card position
3S4YR-SGR
4 (0.16)
4.5 max. (0.18)
40
(1.57)
16.5 (0.65)
3 (0.12)
IC Card
68
(2.68)
60
(2.36)
76
(2.99)
54.3
(2.14)
2.7
(0.11)
IC contacts (front)
Insert
4-ø3.5
IC contact
57 (2.24)
126 (4.96)
27.5
(1.08)
1 (0.04)
50 (1.97)
25 (0.98)
20 (0.78)
5 (0.20)
21 (0.83)
NOTE: DIMENSIONS SHOWN ARE IN MILLIMETERS. To convert millimeters to inches divide by 25.4.
R
One East Commerce Drive
Schaumburg, IL 60173
OMRON ELECTRONICS, INC.
OMRON CANADA, INC.
1-800-55-OMRON
Cat. No. GC CR3
7/00
Specifications subject to change without notice.
4
416-286-6465
885 Milner Avenue
Scarborough, Ontario M1B 5V8
Printed in U.S.A.
