Manual Swipe Magnetic Card Reader
Peripheral-type, Compact, Manually
Operated Card Reader
H
Connects to the PC RS-232C port just
like any other peripheral
3S4YR-HNF
H
Sits conveniently next to the PC
keyboard
H
Easy-to-operate protocol
H
Wide range of configurations available
H
No external power supply required
Ordering Information
Magnetic tracks supported (R, R/W)
1
R
R
—
—
R
R
—
—
—
—
—
—
—
R
R
2
R
R
R
R
R
R
R
R
—
—
R
R
R
R
R
3
R
R
—
—
—
—
R
R
—
—
—
—
—
—
—
Center
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
JISII
—
—
—
—
—
—
—
—
R
R
R
R
R
R
R
IC contact
No
No
No
No
No
No
No
No
No
No
No
No
No
No
No
Interface
RS 232C
RS 232C
RS 232C
RS 232C
RS 232C
RS 232C
RS 232C
RS 232C
RS 232C
RS 232C
RS 232C
RS 232C
RS 232C
RS 232C
RS 232C
Communication
(See Note 1,2,3)
Unidirectional
Bidirectional
Unidirectional
Bidirectional
Unidirectional
Bidirectional
Unidirectional
Bidirectional
Bidirectional
Bidirectional
Unidirectional
Bidirectional
Bidirectional
Bidirectional
Bidirectional
Cover
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
No
Yes
Yes
No
Yes
No
Cable
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
No
Yes
Yes
No
Yes
No
Color
Ivory
Ivory
Ivory
Ivory
Ivory
Ivory
Ivory
Ivory
Ivory
Ivory
Ivory
Ivory
Ivory
Ivory
Ivory
Part Number
3S4YR-HNF1
3S4YR-HNF1-002
3S4YR-HNF4
3S4YR-HNF4-002
3S4YR-HNF6
3S4YR-HNF6-002
3S4YR-HNF7
3S4YR-HNF7-002
3S4YR-HNF2-002
3S4YR-HNF2-012
3S4YR-HNF24
3S4YR-HNF24-002
3S4YR-HNF24-012
3S4YR-HNF26-002
3S4YR-HNF26-012
Note: 1. Communication protocol comes in two types: Unidirectional = response only, and Bidirectional = command/response
2. For information regarding keyboard wedge interface models, contact your Omron representitive.
3. Bidirectional models derive power from the keyboard port, unidirectional models derive power directly from the RS--232 port.
J
TYPICAL APPLICATIONS
S
S
S
S
POS Systems
Credit Card Readers
ID Card Checkers
PC Peripherals
3S4YR-HNF
3S4YR-HNF
Specifications
Part number
Recommended card type
Recording method
Swipe direction
Communication protocol
Card feeding speed
Interface connector
Mounting location
Power supply
Current consumption
Ambient temperature
Ambient humidity
Vibration endurance
Shock endurance
Cable length
Dimensions
Weight
Service life
Operation
Storage
Operation
Storage
HNF
ISO 7810, 7811-1 to -5, 7812 & 7813
F2F
Reads in either direction
Unidirectional (response only) or Bidirectional (command/response)
100 to 1,000 mm/sec. (200 to 1,000 mm/sec. for 3 track stripe card)
D--sub 9--pin (female) Bidirectional units also have PS/2 connector (mini-din 6-pin)
Indoors; away from rain, sunlight and dust
Unidirectional: powered from RS-232C port
Bidirectional: powered from keyboard port
Unidirectional, 12 mA dual track, 16 mA triple track
0 to 45_C (32 to 113_F)
--15 to 60_C (5 to 140_F)
30 to 85% RH, with no condensation and absolute air humidity of 23 g/m
3
or less
20 to 90% RH, with no condensation and absolute air humidity of 40 g/m
3
or less
10 to 150 Hz, single vibration width of 0.15 mm or an acceleration of 19.6 m/s
2
(2 G)
196 m/s
2
(20 G)
1500 mm (59.06)
100 L x 38.6 W x 35.2 H mm (3.94 L x 1.52 W x 1.39 H in)
Approx. 185 g (6.53 oz)
300,000 passes minimum
I/O Information
J
INTERFACE CONNECTOR
D-Sub 9-pin (female). Bidirectional uses 6-pin mini-din (male and female)
J
INTERFACE METHOD
Conforms to EIA RS-232C
Transmission speed: 9600 bps
Communication method: Half-duplex
Synchronizing method: Start-stop synchronization
Data bit length: 8 bits
Error detection: Even parity
Stop bit: 1 bit
4
