Capacitive Touch Sensing ICs
B6TS
OMRON expands its switch product range
by introducing the new touch sensor
switch family B6TS which is based on a
capacitive measurement principle:
• B6TS-04LT – 4 channel sensor
• B6TS-08NF – 8 channel sensor
• B6TS-16NF – 16 channel sensor
(Release 2007)
Features
•
B6TS is ‘Application
Ready’
The B6TS was developed to be
highly tolerant of its working environment with adaptive features
such as self teaching, auto threshold and intelligent filtering to meet
the demands of most applications today. B6TS resists EMC and
compensates continuously for long-term drift.
•
The customer has the ‘Freedom
to Design’
With the exception of a
few rules of thumb you are limited only by your imagination. Panel
designers are free to decide electrode size, shape, spacing etc.
The design is quick and easy – simulation, pcb design, cover mate-
rial design, assembly – Finished Panel Solution!
•
‘Freedom
in Material’
You can make touch keys through any non-
conducting panel material including plastic, rubber, glass, marble
and wood. You can use low cost commercial PCB materials to cre-
ate your designs. Most designs can be done on low cost single
sided PCB like FR-2 or CEM-1.
•
‘Standard
or custom’
B6TS is µController based, so we can pro-
vide off the shelf solutions as well as “quick to market” customized
types. Additional features may be possible at very low development
cost.
Tools
•
Excellent Tool support enables the customer to have an easy entry
in the capacitive sensing technology and customized panel solu-
tions.
■
Evaluation kit ‘B6T Workbench’
which includes
•
A PC tool to program custom parameters of the B6TS like: (Sensi-
tivity adjustment, hysteresis, timing to judge a touch event, drift-
compensation, output mode selectable -> a) momentary switching
b) latching switching c) serial data via SPI interface)
•
RS232 to SPI interface board
•
Demo panel for either (4, 8 or 12 channels) to have an application
ready evaluation platform available. The demo panel can be used
to immediately carry out investigations with different cover materi-
als and geometries.
■
Simulation Software
To evaluate the behavior of the custom panel design before making a
PCB.
■
Application Note
Touch panel reference design.
Target Applications
•
•
•
•
•
•
•
Dish washer
Washing machine
Oven
Fitness equipment
Television
Medical equipment
HVAC controls
•
•
•
•
•
•
•
Lighting controls
Elevator
Automatic door
Vending machine
Alarm clock
In general Man Machine Interfaces (MMI)
