LAMINATED TRANSFORMERS
Type UI30 / 16.5
- 10VA
AGENCY
APPROVALS
1.
UL 506, File E113449
3.
EN61558
V
DE
Primary
(V)
2x115
2x115
2x115
2x115
2x115
Secondary
(V / mA)
6/833
/
6/833
9/555
/
9/555
12/416
/
12/416
15/333/
/
15/333
18/277
/
18/277
No-Load
Voltage
(V)
9.00/9.00
13.40/13.40
17.20/17.20
21.70/21.70
24.80/24.80
Part
Number
030-7073.0
030-7076.0
030-7079.0
030-7082.0
030-7085.0
Agency
Approvals1
1/3*
1/3*
1/3*
1/3*
1/3*
2x115
21/238
/
21/238
29.50/29.50
030-7088.0
1
*NOTE:
When checking the approval status of this product with VDE, add the prefix
"BV" and the suffix "L" to the orderable Part Number (these letters will also be found
on the part label).
The prefix and suffix are not part of the orderable Part Number.
Frequency 50/60Hz
Potted under vacuum
Split-bobbin
Temperature class ta 40°C/B
Weight: 0.24kg
Packaging unit: 15 pieces (tray)
Fixing material for 2,5mm (0.098 inch)
•
Self-tapping screws: DIN 7513 (M 3x8)
•
Sheet-metal screws: DIN 7971 (2,9x6,5)
Mechanical
2,5
(0.098)
44
(1.73)
37,5
(1.48)
12
5
10
7
47,5 (1.87)
53 (2.09)
40 (1.57)
7
(0.28)
16
1
14
3
Ø 2,1
(0.083)
28
(1.10)
4
(0.16)
10
(0.39)
35 (1.38)
Pin Ø 0,8 mm
(Pin DIA. 0.031)
Schematics
230 V
115 V
115 V
115 V
115 V
115 V
1
3
5
7
1
3
5
7
1
3
5
36
(1.41)
7
1
3
7x5
(7x0.2)
5
7
16
14
12
10
16
14
12
10
16
14
12
10
16
14
12
10
sec 1
sec 2
sec 1
sec 2
double voltage
double current
USA 858 674 8100
•
Germany 49 7032 7806 0
•
Singapore 65 6287 8998
•
Shanghai
86 21 54643211 / 2
•
China 86 769 85538070
•
Taiwan 886 3 4641811
www.pulseeng.com
27
LT2007 (9/07)
