LAMINATED TRANSFORMERS
Type EI54 / 18.8
- 16VA
AGENCY
APPROVALS
1.
UL 506, File E113449
3.
EN61558
V
DE
Primary
(V)
230
230
230
230
230
230
230
230
Secondary
(V / mA)
6 / 2666
9 / 1777
12 / 1333
15 / 1066
18 / 888
24 / 666
2x6 / 1333
2x9 / 888
2x12 / 666
No-Load Schematic
Voltage
(V)
No.
7.60
11.30
14.90
18.40
22.40
29.60
2x7.70
2x11.40
2x15.00
1
1
1
1
1
1
2
2
2
Part
Number
054-5381.0
054-5382.0
054-5383.0
054-5384.0
054-5385.0
054-5386.0
054-5387.0
054-5388.0
054-5389.0
Agency
Approvals
1/3*
1/3*
1/3*
1/3*
1/3*
1/3*
1/3*
1/3*
1/3*
Frequency 50/60Hz
Potted under vacuum
Split-bobbin
Temperature class ta 40°C/B
Weight: 0.43kg
Packaging unit: 10 pieces (tray)
230
230
2x15 / 533
2x18.70
2
054-5390.0
1/3*
*NOTE:
When checking the approval status of this product with VDE, add the prefix
"BV" and the suffix "K" to the orderable Part Number (these letters will also be found
on the part label).
The prefix and suffix are not part of the orderable Part Number.
Mechanical
(6 x 0.2)
5
5
5
5
5
5
4,2
(0.165)
1 2
51
(2.00)
37,5
(1.48)
3
4
5 6
7
30
(11.8)
14 13 12 11 10 9
8
10
(0.39)
59
(2.32)
65
(2.56)
38,8
(1.53)
3,5
(0.14)
Pin Ø 0,8 mm
(Pin DIA. 0.031)
75,3
(2.97)
Schematics
No. 1
7
9
No. 2
7
8
9
13
1
13
1
14
USA 858 674 8100
•
Germany 49 7032 7806 0
•
Singapore 65 6287 8998
•
Shanghai
86 21 54643211 / 2
•
China 86 769 85538070
•
Taiwan 886 3 4641811
www.pulseeng.com
19
LT2007 (9/07)
