LAMINATED TRANSFORMERS
Type UI30 / 10.5
- 6VA
AGENCY
APPROVALS
1.
UL 506, File E113449
3.
EN61558
V
DE
Primary
(V)
2x115
2x115
2x115
2x115
2x115
Secondary
(V / mA)
6/500
/
6/500
9/333
/
9/333
12/250
/
12/250
15/200
/
15/200
18/166
/
18/166
No-Load
Voltage
(V)
8.50/8.50
12.70/12.70
16.30/16.30
20.30/20.30
24.30/24.30
Part
Number
030-7004.0
030-7007.0
030-7010.0
030-7013.0
030-7016.0
Agency
Approvals1
1/3*
1/3*
1/3*
1/3*
1/3*
2x115
21/142
/
21/142
28.30/28.30
030-7019.0
1
*NOTE:
When checking the approval status of this product with VDE, add the prefix
"BV" and the suffix "L" to the orderable Part Number (these letters will also be found
on the part label).
The prefix and suffix are not part of the orderable Part Number.
Frequency 50/60Hz
Potted under vacuum
Split-bobbin
Temperature class ta 40°C/B
Weight: 0.175kg
Packaging unit: 15 pieces (tray)
Fixing material for 2,5mm (0.098 inch)
•
Self-tapping screws: DIN 7513 (M 3x8)
•
Sheet-metal screws: DIN 7971 (2,9x6,5)
Mechanical
2,5
(0.098)
44
(1.73)
37,5
(1.48)
12
5
10
7
47,5
(1.87)
53
(2.09)
40
(1.57)
7
(0.28)
16
1
14
3
Ø 2,1
(0.083)
22
(0.87)
4
(0.16)
10
(0.39)
35
(1.38)
Pin Ø 0,8 mm
(Pin DIA. 0.031)
Schematics
230 V
115 V
115 V
115 V
115 V
115 V
1
3
5
7
1
3
5
7
1
3
5
36
(1.41)
7
1
3
7x5
(7x0.2)
5
7
16
14
12
10
16
14
12
10
16
14
12
10
16
14
12
10
sec 1
sec 2
sec 1
sec 2
double voltage
double current
