LAMINATED TRANSFORMERS
Type EI42 / 14.8
- 5VA
AGENCY
APPROVALS
1.
UL 506, File E113449
3.
EN61558
V
DE
Primary
(V)
230
230
230
230
230
230
230
230
Secondary
(V / mA)
6 / 834
9 / 556
12 / 417
15 / 334
18 / 278
24 / 208
2x6 / 417
2x9 / 278
2x12 / 208
No-Load Schematic
Voltage
(V)
No.
8.10
12.00
15.50
19.20
23.20
30.50
2x7.80
2x11.60
2x15.20
1
1
1
1
1
1
2
2
2
Part
Number
042-5381.0
042-5382.0
042-5383.0
042-5384.0
042-5385.0
042-5386.0
042-5387.0
042-5388.0
042-5389.0
Agency
Approvals
1/3*
1/3*
1/3*
1/3*
1/3*
1/3*
1/3*
1/3*
1/3*
Frequency 50/60Hz
Potted under vacuum
Split-bobbin
Temperature class ta 70°C/B
Weight: 0.2kg
Packaging unit: 15 pieces (tray)
230
230
2x15 / 167
2x19.40
2
042-5390.0
1/3*
*NOTE:
When checking the approval status of this product with VDE, add the prefix
"BV" and the suffix "G" to the orderable Part Number (these letters will also be found
on the part label).
The prefix and suffix are not part of the orderable Part Number.
Mechanical
(0.2)(0.3) (0.3) (0.2)
5
7,5
7,5 5
1 2
37
(1.46)
10
(0.39)
3
4
5
4,2
(0.165)
25
(1.00)
33
(1.30)
4
(0.16)
Pin Ø 0,8 mm
(Pin DIA. 0.031)
10 9
8
7 6
46
(1.81)
55
(2.17)
64
(2.52)
Schematics
No. 1
5
7
No. 2
5
6
7
9
1
9
1
10
USA 858 674 8100
•
Germany 49 7032 7806 0
•
Singapore 65 6287 8998
•
Shanghai
86 21 54643211 / 2
•
China 86 769 85538070
•
Taiwan 886 3 4641811
www.pulseeng.com
17
LT2007 (9/07)
