Electrical Specifications @ 25°C - Operating Temperature -40°C to 130°C
5
Part
3,4
Number
OPERATIONAL INSULATION
PA2001NL
PA2002NL
PA2004NL
PA2005NL
PA2006NL
PA2007NL
PA2008NL
PA2009NL
1:1
1:1:1
1:1:1
1:1:1
1:1
1:1
2:1:1
2.5:1:1
1500
1500
1500
1500
1500
1500
1500
1500
12
60
20
26
26
53
52
47
403
1800
437
840
864
1490
1425
1486
4.
5.
6.
0.46
0.60
0.85
0.75
0.75
0.80
0.80
0.80
0.60
1.60
0.85
1.05
0.82
1.15
1.15
1.15
0.60
1.60
0.85
1.05
0.82
1.15
0.575
0.425
8.6 x 6.7 x 2.5
9.0 x 8.6 x 7.6
8.6 x 6.7 x 3.6
11.8 x 8.8 x 4.0
11.8 x 8.8 x 4.0
9.0 x 8.6 x 7.6
9.0 x 8.6 x 7.6
9.0 x 8.6 x 7.6
Turns
Ratio
Pri-Sec
Isolation
(VRMS)
MAX
1
V*µsec
Primary
Inductance
(µH MIN)
Leakage
2
Inductance
(µH MAX)
DCR
Primary
(Ω MAX)
DCR
Secondary
(Ω MAX)
Package Size
(L x W x H)
(mm MAX)
BASIC INSULATION (1.4MM CREEPAGE AND CLEARANCE BETWEEN PRIMARY AND SECONDARY)
Notes:
1. The maximum volt-µsec limits the peak flux density to 2800 Gauss when used in a
unipolar drive application. For bi-polar drive applications, a maximum volt-µsec of
two times this rating is acceptable (i.e. 2* (volt*µsec rating) Volt*µsec = (voltage
applied to the primary) * dutycycle / Frequency = V * alpha / Freq_ Hz = V *
µsec
2. Leakage inductance is measured at primary terminals with all secondaries shorted.
3. Optional Tape & Reel packaging can be ordered by adding a “T” suffix to the part
number (i.e. PA2002NL becomes PA2002NLT). Pulse complies to industry standard
tape and reel specification EIA481.
The “NL” suffix indicates an RoHS-compliant part number.
The temperature of the component (ambient plus temperature rise) must be within
the stated operating temperature range.
Continuous isolation voltage confirmed by 125°C/1000hrs accelerated aging with the
bias voltage applied between primary and secondary windings.
Mechanical
Schematic
0.365
9,27
PA2001NL
.340
MAX
8,64
1
6
6
4
Weight
.........................0.28 grams
Tape & Reel
.....................1500/reel
Tube
...................................60/tube
Dimensions:
Inches
mm
Unless otherwise specified,
all tolerances are
±
.010
0,25
1
Date Code
Country of Origin
PA2001NL
4X
.100
2,54
.265
MAX
6,73
0.07
1,78
3
.200
5,08
.098
MAX
2,49
.005/0,13
4 SURFACES
3
.240
6,1
4
SUGGESTED PAD LAYOUT
P663. K (08/18)
1
power.pulseelectronics.com
http://www.power.pulseelectronics.com/contact
High Isolation Power Transformers
PA200xNL Basic and Operational Insulation
Mechanicals
(CONTINUED)
PA2002NL
Schematics
3
1
8
PA2002NL
6
4
5
Weight
.........................0.60 grams
Tape & Reel
......................400/reel
Tube
...................................50/tube
Dimensions:
Inches
mm
Unless otherwise specified,
all tolerances are
±
.010
0,25
Mechanicals
PA2004NL
.340
MAX
8,64
1
6
Schematics
.355
9,27
1
6
2
1
6
.200
5,08
.100
.070
2,54
1,78
5
3
4
Weight
.........................0.23 grams
Tape & Reel
......................800/reel
Tube
...................................75/tube
Dimensions:
Inches
mm
Unless otherwise specified,
all tolerances are
±
.010
0,25
2
Date Code
Country of Origin
3
.140
4X
3,56
PA2004NL
5
.265
MAX
6,73
.200
5,08
0.07
1,78
.100
2,54
4
3
.220
.240
5,59
4
.140
MAX
3,56
.005/0,13
4 SURFACES
6,1
.320
8,13
SUGGESTED PAD LAYOUT
2
power.pulseelectronics.com
P663. K (08/18)
http://www.power.pulseelectronics.com/contact
High Isolation Power Transformers
PA200xNL Basic and Operational Insulation
Mechanical
(CONTINUED)
PA2005NL, PA2006NL
.460
11,68
.430
10,92
.330
8,38
1
.340
8,64
6
Schematic
PA2005NL
2
.070
1,78
1
6
5
3
4
Date Code
Country of Origin
.170
4,32
.330
8,38
.100
2,54
3
4
PA2005NL
PA2006NL
.250
6,35
.320
8,13
1
3
PA2006NL
6
4
SUGGESTED PAD LAYOUT
.160
4,06
MAX
Weight
..........................0.48 grams
Tape & Reel
......................900/reel
Tube
...................................60/tube
Dimensions:
Inches
mm
Unless otherwise specified,
all tolerances are
±
.010
0,25
.005/0,13
6 SURFACES
Mechanicals
PA2007NL, PA2008NL, PA2009NL
Schematics
PA2008NL / PA2009NL
3
6
4
5
1
8
PA2007NL
1
8
4
5
Weight
.........................0.60 grams
Tape & Reel
......................400/reel
Tube
...................................50/tube
Dimensions:
Inches
mm
Unless otherwise specified,
all tolerances are
±
.010
0,25
3
power.pulseelectronics.com
* for PA2007NL the pads for pins 3 and 6 in the suggested pad layout
should not be used in the layout
P663. K (08/18)
http://www.power.pulseelectronics.com/contact
High Isolation Power Transformers
PA200xNL Basic and Operational Insulation
For More Information
Pulse Worldwide
Pulse Europe
Headquarters
Pulse Electronics GmbH
15255 Innovation Drive Ste 100
Am Rottland 12
San Diego, CA 92128
58540 Meinerzhagen
U.S.A.
Germany
Pulse China Headquarters
Pulse Electronics (ShenZhen) CO., LTD
D708, Shenzhen Academy of
Aerospace Technology,
The 10th Keji South Road,
Nanshan District, Shenzhen,
P.R. China 518057
Tel: 86 755 33966678
Fax: 86 755 33966700
Pulse North China
Room 2704/2705
Super Ocean Finance Ctr.
2067 Yan An Road West
Shanghai 200336
China
Tel: 86 21 62787060
Fax: 86 2162786973
Pulse South Asia
3 Fraser Street
0428 DUO Tower
Singapore 189352
Pulse North Asia
1F., No.111 Xiyuan Rd
Zhongli City
Taoyuan City 32057
Taiwan (R.O.C)
Tel: 858 674 8100
Fax: 858 674 8262
Tel: 49 2354 777 100
Fax: 49 2354 777 168
Tel: 65 6287 8998
Fax: 65 6280 0080
Tel: 886 3 4356768
Fax: 886 3 4356820
