SMT Power Inductors
Power Beads - PA4025.XXXHL Series
Current Rating:
Over 86Apk
Inductance Range:
150nH to 360nH
Height:
12.3mm Max
Footprint:
10.0mm x 6.8mm Max
Halogen Free
Inductance
1
@ 0A
DC
(nH +/- 10%)
150
180
230
360
470
Electrical Specifications @ 25°C — Operating Temperature - 40°C to +130°C
7
Saturation Current
5
Inductance
2
3
4
Irated
DCR
(A TYP)
@Irated
(ADC)
(mW nominal)
(nH TYP)
25°C
100°C
150
58
75+
75+
180
58
75+
75+
0.29 +/- 10%
185
62
75
62
350
36
46
36
460
25
35
25
Electronics
Part
Number
PA4025.151HL
PA4025.181HL
PA4025.231HL
PA4025.361HL
PA4025.471HL
Heating Current
6
(A TYP)
58
NOTES:
1. Inductance measured at 100kHz, 100mVrms.
2. Inductance at Irated is the value of the inductance at 25°C at the listed rated current.
3. The rated current as listed is either the saturation current (25°C or 100°C) or the heating current depending on
which value is lower.
4. The nominal DCR is measured from point a to point b , as shown below on the mechanical drawing.
5. The saturation current is the typical current which causes the inductance to drop by 20% at the stated ambient
temperatures (25°C, 100°C ). This current is determined by placing the component in the specified ambient envi-
ronment and applying a short duration pulse current
(to eliminate self-heating effects) to the component.
6. The heating current is the DC current which causes the part temperature
to increase by approximately 40°C when used in a typical application.
7. In high volt*time applications, additional heating in the component can occur due to core losses in the inductor
which may neccessitate derating the current in order to limit the temperature rise of the component. To deter-
mine the approximate total losses (or temperature rise) for a given application, the coreloss and temperature
rise curves can be used.
8. Optional Tape & Reel packaging can be ordered by adding a “T” suffix to the part number (i.e. PA4025.361HL
becomes PA4025.361HLT).
Pulse complies to industry standard tape and reel specification EIA481. The tape and reel for this product has a
width (W=32mm), pitch (Po=16mm) and depth (Ko=13mm).
9. The temperature of the component (ambient plus temperature rise) must be within the stated operating tem-
perature range.
Mechanical
PA4025.XXXHL
M1
CN
Schematics
Weight
. . . . . . . . . . . xx grams
Tape & Reel
. . . . . . . . . xx/reel
Dimensions:
Inches
mm
Unless otherwise specified,
all tolerances are ± .010
0,25
1
pulseelectronics.com
P733.B (02/15)
Pulse Jack
SMT Power Inductors
Power Beads - PA4025.XXXHL Series
PA4025.XXXHL CoreLoss (W)
0.7
0.6
0.5
0.4
0.3
0.2
0.1
0.0
700
KHz
600
KHz
500
KHz
400
KHz
Electronics
CoreLoss (W)
300
KHz
200
KHz
0
500
1000
1500
2000
B
where B = 0.24 * L(nH) * I
PA4025.XXXHL Temp Rise vs Power Dissipation
Temp Rise above Ambient (C)
50
40
30
20
10
0
0
0.2
0.4
Power (W)
0.6
0.8
1
Total Power Dissipation (W) = CopperLoss + CoreLoss
CopperLoss = Irms^2 * Rdc(mOhms) / 1000
CoreLoss = (from table)
For More Information
Pulse Worldwide
Headquarters
12220 World Trade Drive
San Diego, CA 92128
U.S.A.
Pulse China Headquarters
Pulse North China
Pulse South Asia
Pulse North Asia
B402, Shenzhen Academy of
Room 2704/2705
135 Joo Seng Road
3F, No. 198
Aerospace Technology Bldg.
Super Ocean Finance Ctr.
#03-02
Zhongyuan Road
10th Kejinan Road
2067 Yan An Road West
PM Industrial Bldg.
Zhongli City
High-Tech Zone
Shanghai 200336
Singapore 368363
Taoyuan County 320
Nanshan District
China
Taiwan R. O. C.
Shenzen, PR China 518057
Tel: 886 3 4356768
Tel: 858 674 8100
Tel: 49 7032 7806 0
Tel: 86 755 33966678
Tel: 86 21 62787060
Tel: 65 6287 8998
Fax: 886 3 4356823 (Pulse)
Fax: 858 674 8262
Fax: 49 7032 7806 135
Fax: 86 755 33966700
Fax: 86 2162786973
Fax: 65 6287 8998
Fax: 886 3 4356820 (FRE)
Performance warranty of products offered on this data sheet is limited to the parameters specified. Data is subject to change without notice. Other brand and product names mentioned herein may be
trademarks or registered trademarks of their respective owners. © Copyright, 2015. Pulse Electronics, Inc. All rights reserved.
Pulse Europe
Einsteinstrasse 1
D-71083 Herrenberg
Germany
3
pulseelectronics.com
P733.B (02/15)
