SMT POWER INDUCTORS
Unshielded Drum Core - PB2020NL Series
Height:
10.2mm Max
Footprint:
23.9mm x 20.8mm Max
Current Rating:
up to 30A
Inductance Range:
0.68µH to 33µH
Electrical Specifications @ 25°C — Operating Temperature -40°C to +130°C
Part
6,7
Number
PB2020.681NL
PB2020.102NL
PB2020.222NL
PB2020.332NL
PB2020.472NL
PB2020.682NL
PB2020.103NL
PB2020.153NL
PB2020.223NL
PB2020.333NL
Inductance
@ 0 A
DC
(µH ±20%)
0.68
1.20
2.20
3.30
4.70
6.80
10.00
15.00
22.00
33.00
Inductance
2
@ Irated
(µH TYP)
0.62
1.20
1.90
3.40
4.40
5.90
8.40
14.00
19.00
31.00
Irated
3
(A
DC
)
30.0
23.7
21.8
18.3
16.8
13.6
12.6
9.7
8.1
6.5
DCR
(mΩ)
(TYP)
1.60
2.00
2.60
3.60
4.20
6.10
7.40
12.00
17.00
26.00
(MAX)
1.80
2.20
2.80
3.90
4.50
6.50
7.80
13.00
20.00
29.00
Saturation
4
Current @ 25°C
(A
DC
)
70
55
40
35
28
25
20
18
13
10
Heating
5
Current
(A
DC
)
30.0
23.7
21.8
18.3
16.8
13.6
12.6
9.7
8.1
6.5
NOTES:
1. The temperature of the component (ambient plus temperature rise) must be within
the specified operating temperature range.
2. Inductance at Irated is typical inductance value for component taken at rated current.
3. The rated current listed is the lower of saturation current @ 25°C or heating current.
4. The saturation current, Isat, is the current at which the component inductance drops
by 10% (typical) at an ambient temperature of 25°C. This current is determined by
placing the component in the specified ambient environment and applying a short
duration pulse current (to eliminate self-heating effects) to the component.
5. The heating current, I
DC
, is the DC current required to raise the component
temperature by approximately 40°C. The heating current is determined by mounting
the component on a typical PCB and applying current for 30 minutes.
6. Optional Tape & Reel packaging can be ordered by adding a "T" suffix to the
part number (i.e. PB2020.102NL becomes PB2020.102NLT). Pulse complies to
industry standard tape and reel specification EIA481.
7. The "NL" suffix indicates an RoHS-compliant part number. Non-NL suffixed
parts are not necessarily RoHS compliant, but are electrically and mechanically
equivalent to NL versions. If a part number does not have the "NL" suffix, but
an RoHS compliant version is required, please contact Pulse for availability.
Mechanical
.940
23,87
MAX
.820
20,83
MAX
.400
10,16
MAX
Schematic
1
2
6
SUGGESTED PAD LAYOUT
.960
24,39
.680
17,27
PB2020.XXXNL
Date Code
Country of Origin
INDUCTANCE 0.65 µH TO 4.0 µH
.472
.332
.222
.102
.681
1
4
7
10 13 16 19 22 25 28 31 34 37 40 43
46 49 52
INDUCTANCE ( µH )
.530
13,46
5
4
3
2
1
0
Weight
. . . . . . . .9.5 grams
Tape & Reel
. . . . . .100/reel
Tray
. . . . . . . . . . . . .20/tray
.420
10,67
Dimensions:
Inches
mm
Unless otherwise specified, all tolerances are ± .010
0,25
CURRENT ( A
DC
)
INDUCTANCE 5.78 µH TO 29.0 µH
.333
.223
.153
.103
.682
1
4
7
10
13
16
19
22
25
28
31
34
37
40
35
.950
24,13
1.591
40,41
1.732
± .012
44,00
± 0,30
INDUCTANCE ( µH )
30
25
20
15
10
5
0
TAPE & REEL LAYOUT
.820
20,83
1.260
32,00
USER DIRECTION OF FEED
CURRENT ( A
DC
)
USA 858 674 8100
•
Germany 49 7032 7806 0
•
Singapore 65 6287 8998
•
Shanghai
86 21 54643211 / 2
•
China 86 755 33966678
•
Taiwan 886 3 4641811
www.pulseeng.com
26
SPM2007 (7/08)
