Installation
I
Internal Connections (Top View)
Precautions
I
Circuit Design
Use the DIP Switch within the rated voltage and current ranges,
otherwise the DIP Switch may have a shortened life expectancy, radi-
ate heat, or burn out.
Reflow Soldering
I
Mounting
Do not operate the DIP Switch while mounting, soldering, or washing
the DIP Switch, otherwise the DIP Switch may deform due to the
heat of the solder, the DIP Switch may malfunction due to the pene-
tration of the washing agent, or the machine incorporating the DIP
Switch may operate or be set incorrectly.
An automatic insertion machine incorporating a body stopper is avail-
able for mounting the DIP Switch. When using an automatic insertion
machine incorporating a half-lead stopper to mount the DIP Switch,
make sure that the automatic insertion machine will not deform the
terminals of the DIP Switch, otherwise the improper insertion of the
DIP Switch may result.
Manual Soldering
Soldering temperature:
Soldering time:
350°C at the tip of the soldering iron
3 s max. for a 1.6-mm thick, single-side
PCB
I
Soldering
Observe the following conditions when soldering the DIP Switch.
Set the pins of the DIP Switch to OFF before soldering the DIP
Switch.
Before soldering the DIP Switch on a PCB, make sure that there is
no unnecessary space between the DIP Switch and PCB.
Before soldering the DIP Switch on a multilayer PCB, make sure that
the DIP Switch will not be deformed by the soldering heat on the pat-
tern or land of the multilayer PCB.
Do not solder the DIP Switch more than twice including rectification
soldering. An interval of five minutes is required between the first and
second solderings.
Make sure that there is no flux rise on the surface of the PCB.
Automatic Soldering Bath
Soldering temperature:
Soldering time:
350°C at the tip of the soldering iron
3 s max. for a 1.6-mm thick, single-side
PCB
DIP Switch
A6T/A6S
1193
