series
105
105
6000 10000
6000 10000 hours. Miniaturized, Long Life, Low Impedance
e
compliance
RoHS
SPECIFICATIONS
Item
Category Temperature Range
Rated Voltage Range
Capacitance Tolerance
Characteristics
-40 +105
6.3
100Vdc
±20% 20 , 120Hz
Leakage Current (MAX)
I 0.01CV
3 A
2
I 0.01CV or 3 A whichever is greater.
(After 2 minutes)
I=
A C=
F V=
Vdc
Leakage Current Capacitance
Rated Voltage
(Vdc)
Rated Voltage
6.3
0.22
10
0.19
16
0.16
25
0.14
35
0.12
50
0.10
63
0.09
80
0.08
100
0.08
)
(20 , 120Hz)
tan
Dissipation Factor (MAX)
tan
1000 F
1000 F
0.02
When capacitance is over 1000 F, tan shall be added 0.02 to the listed value with increase of every 1000 F.
105
After applying rated voltage with rated ripple current for specified time at 105 ,
the capacitors shall meet the following requirements.
±25
6.3Vdc, 10Vdc ±30%
Case Size
D 6.3
D 8
D 10
Capacitance Change
Within ±25 of the initial value 6.3Vdc, 10Vdc ±30%
(hrs)
Time(hrs)
6000
8000
10000
Endurance
Dissipation Factor
Leakage Current
(Vdc)
Rated Voltage
Z(-25 )/Z(+20
)
)
6.3
2
3
200%
Not more than 200% of the specified value.
Not more than the specified value.
10
2
3
16
2
3
25
2
3
35
2
3
50
2
3
63
2
3
80
2
3
100
2
3
(120Hz)
Low Temperature Stability
Impedance Ratio (MAX)
Z(-40 )/Z(+20
PART NUMBER
ZLH
Rated Voltage
Series
Capacitance
M
Capacitance Tolerance
Option
Lead Forming
x
Case Size
OPTION
MULTIPLIER FOR RIPPLE CURRENT
(Hz)
Frequency
120
0.42
0.50
0.55
0.60
0.70
1k
0.70
0.73
0.77
0.80
0.85
10k
0.90
0.92
0.94
0.96
0.98
100k
1.00
1.00
1.00
1.00
1.00
EFC : PET
PET Sleeve
8.2 33 F
47 270 F
Coefficient
330 680 F
820 1800 F
2200 8200 F
76
