FQ2 Smart Camera
The N ew Sta n dard for Image Insp ect i on
»
Expanded
»
Advance d inspe c t ion in a com p a c t h o u s in g
p e r fo r m a n c e a n d f u n c t i o n a l i ty
»
Camera, Communications, Software Tools, and Much More
2
Introducing the Smart Heavyweight
Inspection capabilities, camera options, and
communication options -- this powerful heavy-
weight has it all.
This Vision Sensor provides all of the best-selling
features found in high-end models without the
need as in vision system for a separate controller.
This new Smart Camera was designed to attract
potential customers to try the FQ2 Series.
Code High-
speed
Reader
image processor
Megapixel
capacity
Real
color
Monochrome
-mount
C
inspection
items
9
filters
11
-camera
expansion
32
360°
position
compensation
field of view
Ultra-
wide
partial input
DAP
OCR HDR
Sub-pixel High-power
processing
lighting
IP67 E-IP PLC FINS 34 I/O
Link
points
RS-
232C
Password
inversion
OK
1
2
4
4
Reading Barcode
5
NG
NG
OK
3
1
Missing Pill
2
Misalignment
3
Package Insert
Detection
3
Three Improvements for an effective Machine Design
All in one Vision Sensor
Compact
Body
All-in-one compact size that is perfect for use in tight
spaces or as an aftermarket option.
Compared to more-advanced Vision Sensors with mul-
tiple components, this Sensor boasts a much more ef-
ficient hardware design.
p.
04
Image Sensor, OCR, and
Code Reader in One
Extended
Functions
The OCR function, with a "build-in" dictionary and
the Code Reading, ability to recognize 15 codes
types add to the solution and provide a powerful up-
grade !
Date
Verification
2D Code
Inspections
OCR
p.
06
p.
10
Bar Code
Label out of
place
p.
08
Code Reader
A Lineup That Fits a
Wide Range of Equipment
Diverse
Lineup
Expanded inspection menu, camera variations, and com-
munication interfaces with the same pricing level as our
previous FQ Series.
With a wide range of sensors, an option for every applica-
tion now becomes a standard option.
p.
12
OK
OK
OK
5
Hot-melt Detection
6
Date Verification and
7
Reading Barcode
de
Tape Detection
6
7
4
Compact
All You Need is One
All You Need in One Package
Image Processor
Although previous Vision Sensors placed the image pro-
cessor in a separate Controller, now we have built the
processor into the camera unit.
High-power Lighting
The Sensor includes high-power lighting capable of
evenly lighting across a wide field of view.
This provides sufficient lighting even when the en-
closed polarizing filter is used.
s
Adjustable lens
The focus of the lens can
be adjusted to take clear
images for the specific field
of view and installation dis-
tance you need.
Focus adjustment screw
I/O Power Supply Connector
The external output line for inspection results, the input
line for changing the setup, and the power supply line
are all combined into one connector.
Ethernet Connector
Commands can be input from a PLC to control the
FQ2, and inspection results and measurement results
can be output from the FQ2 to a PLC.
You can also transfer images to a computer.
IP67 Water Resistance
Flexible Cables
Smart Click Connectors
1
2
The sensor can be used in wet
environments.
All cables from the camera are flexible.
This allows the Sensor to be used safely
on moving parts.
Connection is made quick and easy with a
clear, definitive click-into-place mecha-
nism.
5
Quick and Easy Design and Installation
Easy Product Selection
All you need to do is select the camera based on the field of view and installation distance that you require. There is no need to select and
purchase additional lighting or lenses. Furthermore, the time required to wire everything has been drastically reduced due to the low
number of components.
Vision Systems
or
more
components
FQ2-series Smart Cameras
Only
7
Controller
Console
Monitor
Camera
Lens
Lighting
Power supply of lighting
2
Sensor
Monitoring and Setup Tool
Touch Finder or Touch Finder for PC
Easy Installation
The camera and lighting have been integrated into a single unit, so only one camera mounting bracket is required. The Sensor comes with
a multi-directional mounting bracket that can be attached on any of the four sides of the Camera. Axis alignment is also not required be-
cause the lighting and the camera are integrated into a single unit.
Standard Vision Cameras
The optical axis must be adjusted
because of two components
are mounted.
1
Mount camera.
2
Mount lighting.
3
Align the optical axes.
3
2
1
FQ2-series Smart Cameras
Only one mounting bracket
Multi-directional Mounting Bracket
Easy Expansion
Up to 32 Cameras
Just install the Cameras where you need them. No control panels are required to house the controllers. Triggers can be input for each
Camera, so new Cameras can be added whenever required without having to worry about timing input design. Up to 32 Cameras can be
set up from a single Touch Finder, so you do not need to worry about adding new monitors when you need more Cameras. This also allows
you to smoothly respond to user requests for additional features.
Current Vision Systems
FQ2-series Smart Cameras
A separate controller is
needed to add a
new camera.
Connect up the
32
Cameras
and remove them as
required after setup.
Triggers
