ECW-FG2J155QA datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Passive components> capacitor> ECW-FG2J155QA

ECW-FG2J155QA: Description1.5 µF 薄膜电容器 141V 630V 聚丙烯（PP），金属化径向; CategoryPassive components capacitor; File Size1MB，26 Pages; ManufacturerPanasonic; Websitehttp://www.panasonic.co.jp/semicon/e-index.html; Environmental Compliance

Download Datasheet Parametric View All

ECW-FG2J155QA Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	ECW-FG2J155QA	-	-	View	Buy Now

ECW-FG2J155QA Overview

1.5 µF 薄膜电容器 141V 630V 聚丙烯（PP），金属化径向

ECW-FG2J155QA Parametric

Parameter Name	Attribute value
category
Maker	Panasonic
series	ECWFG
Package	Bulk
capacitance	1.5 µF
Tolerance	±10%
Rated voltage - AC	141V
Rated voltage - DC	630V
dielectric materials	Polypropylene (PP), metallized
Operating temperature	-40°C ~ 110°C
Installation type	Through hole
Package/casing	Radial
size/dimensions	1.063" 长 x 0.472" 宽（27.00mm x 12.00mm）
Height - Installation (maximum)	0.846"（21.50mm）
Termination	PC pin
lead spacing	0.886"（22.50mm）
application	Automobile; high frequency, switch
grade	AEC-Q200
characteristic	high temperature
Basic product number	ECW-FG

Preview

Download Datasheet

View All

Plastic Film Capacitors

Metallized Polypropylene

Film Capacitor (For Automotive)

ECWFG

series

Features

● High safety (with safety function)

● High moisture resistance (85℃, 85%）

・ 600 V ：420 V, 500 h

・ 630 V ：500 V, 1000 h

・ 700 V ：500 V, 1000 h

・ 800 V ：560 V, 500 h

・ 1100 V ：700 V, 500 h（C < 2.0 μF）/ 770 V, 500 h（C ≧ 2.0 μF）

● High thermal shock resistance (600 to 1100 V : -55℃ ⇔ 85℃, 1000 cycles)

● High temperature load test (125℃）

・ 600 V ：360 V, 1000 h

・ 630 V ：450 V, 1000 h

・ 700 V ：450 V, 1000 h

・ 800 V ：480 V, 1000 h

・ 1100 V ：660 V, 1000 h

● Flame-retardant plastic case and non-combustible resin

● AEC-Q200 compliant

● RoHS compliant

UPGRADE

Non-inductive construction using metallized polypropylene

film with flame retardant plastic case.

Recommended applications

● DC/DC, AC/DC converter circuit in xEV

● High frequency and high current circuits

Explanation of part number

■ Lead pitch : 22.5 mm

Rated voltage

Capacitance

Suffix 1

Suffix 2

Product code

Dielectric &

construction

Code

R.voltage [DC]

630 V

Code

Cap. Tol.

±5 ％（J）

±10 ％（K）

Code

Lead form

Straight

Cut lead

■ Lead pitch : 27.5 mm

Rated voltage

Capacitance

R. volt. code

Product code

Dielectric &

construction

Suffix 1

Suffix 2

Code

R.voltage [DC]

600 V

630 V

700 V

800 V

1100 V

Code

Cap. Tol.

±5 ％

±10 ％

±5 ％

Code

Blank

Lead form

Straight

Cut lead

2J, 70

60, 80, 1B

Design and specifications are each subject to change without notice. Ask factory for the current technical specifications before purchase and/or use.

Should a safety concern arise regarding this product, please be sure to contact us immediately.

10-Feb-21
