1-1624102-6 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Passive components> inductor> 1-1624102-6

1-1624102-6: Description1 ELEMENT, 0.47uH, GENERAL PURPOSE INDUCTOR, SMD, CHIP, 1008, ROHS COMPLIANT; CategoryPassive components inductor; File Size101KB，1 Pages; ManufacturerTE Connectivity; Websitehttp://www.te.com; Environmental Compliance

Download Datasheet Parametric Compare View All

1-1624102-6 Overview

1 ELEMENT, 0.47uH, GENERAL PURPOSE INDUCTOR, SMD, CHIP, 1008, ROHS COMPLIANT

1-1624102-6 Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Objectid	1646062835
package instruction	1008
Reach Compliance Code	compliant
ECCN code	EAR99
uppercase and lowercase codes	1008
DC Resistance	1 Ω
Nominal inductance(L)	0.47 µH
Inductor type	GENERAL PURPOSE INDUCTOR
Manufacturer's serial number	3611
Number of functions	1
Number of terminals	2
Minimum quality factor (at nominal inductance)	20
Maximum rated current	0.155 A
Shape/Size Description	RECTANGULAR PACKAGE
shield	NO
surface mount	YES
Terminal location	DUAL ENDED
Terminal shape	WRAPAROUND
Tolerance	10%

Preview

Download Datasheet

View All

C orporate Hom e

Electronic Components

Se gm e nts

W ho W e Are

My Account

Searc h

Products

Documentation

Resources

My Account

Customer Support

Home

Products

By Type

Passive C omponents

Product Feature Selector

> Product Details

3611TR47K Product Details

Live Product Chat

Inductors

C onve rte d to EU R oHS/ELV C om plia nt

(

Sta te m e nt of C om plia nce

)

Quick Links

C heck Pricing & Availability

Search for Tooling

Product Feature Selector

C ontact Us About This Product

3611TR47K

(1-1624102-6)

T E I nternal N umber: 1 - 1 6 2 4 1 0 2 - 6

Product Highlights:

Inductor

Inductor Type = Molded Wirewound

Lead Type = Surface Mount Terminals

Wirewound

Inductance = .47 ?H

View all Features

A dd to M y P art L is t

Reques t Sample

Find Similar P roduc ts

Active

Buy P roduc t

Documentation & Additional Information

Product Drawings:

SMD C HIP INDUC TOR SERIES 3611T

(PDF, English)

Catalog Pages/Data Sheets:

SMD C hip Inductor - Type 3611 Series - Tyco Electron...

(PDF, English)

Product Specifications:

None Available

Application Specifications:

None Available

Instruction Sheets:

None Available

CAD Files:

None Available

List all Documents

Product Features

(Please use the Product Drawing for all design activity)

Product Type Features:

Product Type

= Inductor

Inductor Type = Molded Wirewound

Element

= Wirewound

Shielded

= No

Electrical Characteristics:

Inductance (?H)

= 0.47

DC Resistance (?)

= 1

C urrent, Maximum (mA)

= 155

Quality Factor

= 20

Package Type

= Taped and Reeled

Tolerance (%) = 10

Body Related Features:

Lead Type

= Surface Mount Terminals

Series

= 3611

Packaging Style

= 1008

Package, C omponent Size

= 2.5 x 2.0

Mount Style

= Surface Mount

Industry Standards:

RoHS/ELV C ompliance

= RoHS compliant, ELV compliant

Lead Free Solder Processes

= Wave solder capable to 240?C

RoHS/ELV C ompliance History = C onverted to comply with RoHS

directive

Operation/Application:

Application

= Standard

Other:

Brand = Sigma Inductors

Additional Information:

Product Line Information

1-1624102-6 Related Products

	1-1624102-6	3611TR47K
Description	1 ELEMENT, 0.47uH, GENERAL PURPOSE INDUCTOR, SMD, CHIP, 1008, ROHS COMPLIANT	1 ELEMENT, 1uH, FERRITE-CORE, GENERAL PURPOSE INDUCTOR, SMD, CHIP, 1008, ROHS COMPLIANT
Is it lead-free?	Lead free	Lead free
Is it Rohs certified?	conform to	conform to
package instruction	1008	1008
Reach Compliance Code	compliant	compliant
ECCN code	EAR99	EAR99
uppercase and lowercase codes	1008	1008
DC Resistance	1 Ω	1 Ω
Nominal inductance(L)	0.47 µH	1 µH
Inductor type	GENERAL PURPOSE INDUCTOR	GENERAL PURPOSE INDUCTOR
Manufacturer's serial number	3611	3611
Number of functions	1	1
Number of terminals	2	2
Minimum quality factor (at nominal inductance)	20	20
Maximum rated current	0.155 A	0.155 A
Shape/Size Description	RECTANGULAR PACKAGE	RECTANGULAR PACKAGE
shield	NO	NO
surface mount	YES	YES
Terminal location	DUAL ENDED	DUAL ENDED
Terminal shape	WRAPAROUND	WRAPAROUND
Tolerance	10%	10%
