3BZ41,3GZ41,3JZ41,3NZ41
TOSHIBA Rectifier Silicon Diffused Type
3BZ41, 3GZ41, 3JZ41, 3NZ41
General Purpose Rectifier Applications
•
•
•
Average Forward Current: I
F (AV)
=
3.0 A (Ta
=
45°C)
Repetitive Peak Reverse Voltage: V
RRM
=
100 V, 400 V, 600 V, 1000 V
Peak One Cycle Surge Forward Current (non repetitive):
I
FSM
=
180 A (50 Hz)
Maximum Ratings
(Ta
=
25°C)
Characteristics
3BZ41
Repetitive peak
reverse voltage
3GZ41
3JZ41
3NZ41
Average forward current (Ta
=
45°C)
Peak one cycle surge forward current
(non repetitive)
Junction temperature
Storage temperature range
I
F (AV)
I
FSM
T
j
T
stg
V
RRM
Symbol
Rating
100
400
600
1000
3.0
180 (50 Hz)
200 (60 Hz)
−40
to 150
−40
to 150
°C
°C
A
A
V
Unit
Electrical Characteristics
(Ta
=
25°C)
Characteristics
Peak forward voltage
Repetitive peak reverse current
Thermal resistance (junction to ambient)
Symbol
V
FM
I
RRM
R
th (j-a)
Test Condition
I
FM
=
3.0 A
V
RRM
=
Rated
DC
Min
Typ.
Max
1.0
10
37
Unit
V
µA
°C/W
Marking
Type Code Lot No.
Code
3BZ
JAPAN
Year (last number of the christian era)
Month (starting from alphabet A)
3BZ
3GZ
3JZ
Cathode Mark
Color: Silver
3NZ
Type
3BZ41
3GZ41
3JZ41
3NZ41
000707EAA2
•
TOSHIBA is continually working to improve the quality and reliability of its products. Nevertheless, semiconductor devices in general
can malfunction or fail due to their inherent electrical sensitivity and vulnerability to physical stress. It is the responsibility of the
buyer, when utilizing TOSHIBA products, to comply with the standards of safety in making a safe design for the entire system, and
to avoid situations in which a malfunction or failure of such TOSHIBA products could cause loss of human life, bodily injury or
damage to property.
In developing your designs, please ensure that TOSHIBA products are used within specified operating ranges as set forth in the
most recent TOSHIBA products specifications. Also, please keep in mind the precautions and conditions set forth in the “Handling
Guide for Semiconductor Devices,” or “TOSHIBA Semiconductor Reliability Handbook” etc..
•
The TOSHIBA products listed in this document are intended for usage in general electronics applications (computer, personal
equipment, office equipment, measuring equipment, industrial robotics, domestic appliances, etc.). These TOSHIBA products are
neither intended nor warranted for usage in equipment that requires extraordinarily high quality and/or reliability or a malfunction or
failure of which may cause loss of human life or bodily injury (“Unintended Usage”). Unintended Usage include atomic energy
control instruments, airplane or spaceship instruments, transportation instruments, traffic signal instruments, combustion control
instruments, medical instruments, all types of safety devices, etc.. Unintended Usage of TOSHIBA products listed in this document
shall be made at the customer’s own risk.
2000-10-31
1/3
3BZ41,3GZ41,3JZ41,3NZ41
i
F
– v
F
20
3.5
3.0
P
F (AV)
– I
F (AV)
(A)
Instantaneous forward current i
F
5
3
Tj
=
150°C
25
Average forward power dissipation
P
F (AV)
(W)
10
2.5
2.0
1
0.5
0.3
1.5
Half sine waveform
1.0
0°
0.5
Conduction angle 180°
180°
0.1
0
0.2
0.4
0.6
0.8
1.0
1.2
1.4
0
0
0.5
1.0
1.5
2.0
2.5
3.0
3.5
Instantaneous forward voltage v
F
(V)
Average forward current I
F (AV)
(A)
Surge forward current (non-repetitive)
Transient thermal impedance
r
th (j-a)
(°C /W)
200
r
th (j-a)
– t
100
(A)
Tj
=
25°C
160
Surge forward current I
FSM
10
10 mm
1
20 mm
×
20 mm
20 mm
0.1
0.001
0.01
0.1
1
10
100
1000
10 mm
120
60
80
50 Hz
40
Time t (s)
0
1
3
5
10
30
50
100
Number of cycles
000707EAA2
•
The information contained herein is presented only as a guide for the applications of our products. No responsibility is assumed by
TOSHIBA CORPORATION for any infringements of intellectual property or other rights of the third parties which may result from its
use. No license is granted by implication or otherwise under any intellectual property or other rights of TOSHIBA CORPORATION or
others.
•
The information contained herein is subject to change without notice.
2000-10-31
2/3
