Power Inductors - Unshielded
ctparts.com
CT636FY Series
From 1.0 µH to 100 µH
Part
Number
CT636FY_-1R0M
CT636FY_-1R5M
CT636FY_-2R2M
CT636FY_-3R3M
CT636FY_-4R7M
CT636FY_-6R8M
CT636FY_-100M
CT636FY_-120M
CT636FY_-150M
CT636FY_-180M
CT636FY_-220M
CT636FY_-270M
CT636FY_-330M
CT636FY_-390M
CT636FY_-470M
CT636FY_-560M
CT636FY_-680M
CT636FY_-820M
CT636FY_-101M
Not shown at actual size.
SPECIFICATIONS
Parts are marked to indicate tolerance available.
M = ±20%
CTC636FYF
Please specify “F” for RoHS Compliant
Inductance
(µH)
1.0
1.5
2.2
3.3
4.7
6.8
10
12
15
18
22
27
33
39
47
56
68
82
100
L Test
Freq.
(kHz)
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
DCR
Max.
Ω
(Ω)
.02
.03
.03
.04
.05
.07
.09
.01
.01
.16
.18
.24
.29
.34
.41
.48
.60
.71
.95
Rated
DC
(A)
2.9
2.7
2.4
2.1
1.9
1.6
1.4
1.3
1.1
1.0
.93
.80
.72
.66
.59
.55
.49
.44
.38
Compliant
Available
RoHS
PHYSICAL DIMENSIONS
Size
A
Max.
7.4
0.29
B
Max.
7.4
0.29
C
Max.
3.5
0.14
D
2.0±0.2
0.08±0.008
E
Max.
5.4
0.21
CHARACTERISTICS
Description:
SMD power inductor
Applications:
Ideal for a variety of DC/DC converter applications
and low profile use
Operating Temperature:
-30°C to +100°C
Inductance Tolerance:
±20%
Testing: Inductance is tested on an HP4285A at 100 kHz
Packaging:
Tape & Reel
Marking:
Parts are marked with inductance code
Miscellaneous:
RoHS Compliant available
Additional Information:
Additional electrical & physical
information available upon request
Samples available. See website for ordering information.
mm
inches
01.14.05
Technologies
Manufacturer of Inductors, Chokes, Coils, Beads, Transformers & Toroids
800-684-5322
Inside US
949-453-1811
Outside US
Copyright © 2005 by CT Magnetics, DBA Central Technologies. All rights reserved.
CT Magnetics reserves the right to make improvements or change specifications without notice
