8.45
5.5
2
10.8
7.8
1
3.2
13.2
4.8
2
3
3.2
4
12.1
0.6
2.5
2.8
10.4
4.8
0.25
0 .3
4
1
0. 9
3
14.7
10.4
2.5
PCB Layout
Revision:
A
A1
Date:
10-22/2015
07/30/2018
Description:
Initial release
Corrected operating temp range
GL
RS
Prepared:
Digitally signed by GL
Date: 2018.08.06
10:51:30 -07'00'
Notes:
RoHS and REACH compliant
Function test: no open, no short circuit, no
intermittent
Description:
Connector, USB B Jack, PCB mount, 90°, nickel shell,
shielded, board lock, white insulator, tray
3
2
tel
fax
Verified:
Digitally signed by RS
Date: 2018.08.09
10:39:09 -07'00'
Dimensions are in
millimeters.
Tolerances:
X:
0.5 mm
X.X:
0.3 mm
X.XX: 0.05 mm
5
4
1.541.323.3228
1.541.323.4202
Part number:
800
web
877.670.7118
tensility.com
Size:
A
Scale:
54-00018
2:1
1
Sheet 1 of 2
11.8
3
2
To see a custom version of this cable assembly, call Tensility at 541-323-3228 or email engineering@tensility.com
16.2
USB B jack 90° PCB mount
12.1
2(
)
x2
(x4
)
Materials
1. Shell, steel, nickel plated
2. Pins, phosphor bronze, 5
μ"
gold and tin plating
3. Insulator, PBT + 30% GF, white, 94 V-0
Electrical
Rated voltage: 30 Vdc
Rated current: 3 A
Dielectric strength: 1 min @ 500 Vac
Insulation resistance: 1000 MΩ @ 500 Vdc
Contact resistance: 30 mΩ or less
Mechanical
Insertion force: 3.5 kgf maximum
Withdrawal force: 1.0 kgf minimum
Durability: 1500 cycle minimum life; less than 100 mΩ
contact resistance, minimum 50 MΩ insulation
resistance
Terminal strength: 0.3 kgf in any direction for 15
seconds without damage or looseness
Soldering
Solderability: 75% minimum coverage when terminals
dipped 2 mm in 245 ±5 °C solder bath for 3 ±0.5
seconds
Solder bath durability: no deformation when immersed
in 255 ±5 °C up to surface of the board for 5 seconds
or less
Solder iron durability: no deformation when exposed to
350 ±10 °C for 3 ±0.5 seconds
Environmental
Cold test: -40 ±3 °C for 48 hours without deformation
Heat test: 85 ±2 °C for 48 hours without deformation
Humidity test: 40 ±2 °C and humidity between 90 and
98 % for 48 hours without deformation
Operating range
-40 ~ 85 °C
Tin
Gold
1
USB B jack 90° PCB mount
3
2
13.2
4.8
2
12.1
Pin plating detail
4
1
0. 9
10.4
2.5
PCB Layout
2(
)
x2
(x4
)
tel
fax
Revision:
A
A1
Date:
10-22/2015
07/30/2018
Description:
Initial release
Corrected operating temp range
Prepared:
GL
Digitally signed by GL
Date: 2018.08.06
10:51:47 -07'00'
Notes:
RoHS and REACH compliant
Function test: no open, no short circuit, no
intermittent
Description:
Connector, USB B Jack, PCB mount, 90°, nickel shell,
shielded, board lock, white insulator, tray
3
2
1.541.323.3228
1.541.323.4202
Part number:
800
web
RS
Verified:
Digitally signed by RS
Date: 2018.08.09
10:39:29 -07'00'
Dimensions are in
millimeters.
Tolerances:
0.5 mm
X:
X.X:
0.3 mm
X.XX: 0.05 mm
5
4
877.670.7118
tensility.com
Size:
A
Scale:
54-00018
2:1
1
Sheet 2 of 2
11.8
3
2
