Corcom H Series
20A Power Line Filters
The H Series filters are suitable for use in medical equipment and
feature a 2 element circuit that provides general purpose performance
above 1MHz with minimal leakage current. The new 20A versions are
for chassis mount installations and offer either spade or threaded bolt
terminations.
KEY FEATURES
•
Minimal leakage current suitable for medical
STANDARDS AND SPECIFICATIONS
•
UL Recognized
•
VDE Approved
•
CSA Pending
equipment
•
Two element circuit provides basic EMI
attenuation above 1MHz
•
Low profile design allows for a space-saving
design solution
•
Compliant with internal spacing
ELECTRICAL SPECIFICATIONS
Line to Ground:
Line to Line:
1500 VAC
1450 VDC
250 VAC
50/60 Hz
20A max.
requirements for UL60601-1, 3
rd
edition
for medical applications
•
Capacitive input
•
Designed for easy connection and
Hipot rating (one minute):
Rated Voltage:
Operating Frequency:
Rated Current:
installation
APPLICATIONS
•
Dialysis machines
•
Diagnostic equipment
•
Medical laser
•
CAT scanners
•
MRT scanners
•
Dentist equipment
•
Operating room equipment
•
Physical therapy equipment
ELECTRICAL SCHEMATIC
LINE
LOAD
ORDERING INFORMATION
PRODUCT OFFERING
20 E H 1
3-1609037-8:
4-1609037-3:
Samples Available
20EH1
20EH6
20A H Series filter with spade terminals
20A H Series filter with threaded bolt terminals
Input / Output Style
1 – .250 [6.3] spade terminals
6 – Threaded bolts
H Series
Leakage Current Designation
E – Low Leakage
(<0.5 mA)
Current Rating
20A
corcom.com
1-1773704-2 JG2 PDF 09/2013
© 2013 Tyco Electronics Corporation, a TE Connectivity Ltd. Company. All Rights Reserved.
Corcom, TE Connectivity and TE connectivity (logo) are trademarks. Other logos, product and/or
company names might be trademarks of their respective owners.
USA: 1-800-522-6752
Canada: +1-905-475-6222
Mexico: +52 (0) 55-1106-0800
Latin/S. America: +54 (0) 11-4733-2200
Germany: +49 (0) 6251-133-1999
UK: +44 (0) 800-267666
France: +33 (0) 1-3420-8686
Netherlands: +31 (0) 73-6246-999
China: +86 (0) 400-820-6015
TE Connectivity
CASE STYLES
20EH1
20EH6
Corcom H Series 20 Power Line Filters
C
D
C
D
B
B
A
A
DIMENSIONS
A
B
C
D
Part Numbers
(max)
(max)
(max)
± .015
± .38
20EH1
20EH6
3.35
85
3.35
85
2.07
52.6
2.07
52.6
1.31
33.3
1.53
38.9
2.94
74.63
2.94
74.63
PERFORMANCE DATA
Minimum Insertion Loss
-
Measured in closed 50 Ohm system
Common Mode / Asymmetrical (Line to Ground)
Frequency — MHz
Current Rating
.15
.5
1
5
10
30
Current Rating
.15
.5
Differential Mode / Symmetrical (Line to Line)
Frequency — MHz
1
5
10
30
20A
10
20
21
15
15
15
20A
-
1
5
20
30
25
Dimensions in inches and millimeters unless otherwise shown. Values in italics are metric equivalents.
Dimenions are shown for reference purposes only. Specifications subject to change.
Customer drawing should be used for all design activity.
