KTC3228Y: DescriptionSmall Signal Bipolar Transistor, 1A I(C), 160V V(BR)CEO, 1-Element, NPN, Silicon, TO-92L, 3 PIN; CategoryDiscrete semiconductor The transistor; File Size482KB，3 Pages; ManufacturerKEC; Websitehttp://www.keccorp.com/

Download Datasheet Parametric Compare View All

KTC3228Y Overview

Small Signal Bipolar Transistor, 1A I(C), 160V V(BR)CEO, 1-Element, NPN, Silicon, TO-92L, 3 PIN

KTC3228Y Parametric

Parameter Name	Attribute value
Maker	KEC
Parts packaging code	TO-92L
package instruction	IN-LINE, R-PSIP-T3
Contacts	3
Reach Compliance Code	unknown
ECCN code	EAR99
Maximum collector current (IC)	1 A
Collector-emitter maximum voltage	160 V
Configuration	SINGLE
Minimum DC current gain (hFE)	160
JESD-30 code	R-PSIP-T3
Number of components	1
Number of terminals	3
Maximum operating temperature	150 °C
Package body material	PLASTIC/EPOXY
Package shape	RECTANGULAR
Package form	IN-LINE
Polarity/channel type	NPN
Maximum power dissipation(Abs)	1 W
surface mount	NO
Terminal form	THROUGH-HOLE
Terminal location	SINGLE
transistor applications	AMPLIFIER
Transistor component materials	SILICON
Nominal transition frequency (fT)	100 MHz
Base Number Matches	1

Preview

Download Datasheet

View All

SEMICONDUCTOR

TECHNICAL DATA

COLOR TV VERT. DEFELECTION OUTPUT APPLICATION.

COLOR TV CLASS B SOUND OUTPUT APPLICATION.

KTC3228

EPITAXIAL PLANAR NPN TRANSISTOR

FEATURES

・High

Voltage : V

CEO

=160V.

・Large

Continuous Collector Current Capability.

・Recommended

for Vert. Deflection Output & Sound Output

Applications for Line Operated TV.

・Complementary

to KTA1275.

DEPTH:0.2

DIM

MILLIMETERS

7.20 MAX

5.20 MAX

0.60 MAX

2.50 MAX

1.15 MAX

1.27

1.70 MAX

0.55 MAX

14.00 + 0.50

0.35 MIN

0.75 + 0.10

MAXIMUM RATING (Ta=25℃)

CHARACTERISTIC

Collector-Base Voltage

Collector-Emitter Voltage

Emitter-Base Voltage

Collector Current

Base Current

Collector Power Dissipation

Junction Temperature

Storage Temperature Range

SYMBOL

CBO

CEO

EBO

stg

RATING

160

0.5

150

-55½150

UNIT

℃

1. EMITTER

2. COLLECTOR

3. BASE

1.25

Φ1.50

0.10 MAX

12.50 + 0.50

1.00

TO-92L

ELECTRICAL CHARACTERISTICS (Ta=25℃)

CHARACTERISTIC

Collector Cut-off Current

Emitter Cut-off Current

Collector-Emitter Breakdown Voltage

DC Current Gain

Collector-Emitter Saturation Voltage

Base-Emitter Voltage

Transition Frequency

Collector Output Capacitance

Note : h

Classification

R:60½120

SYMBOL

CBO

EBO

(BR)CEO

(Note)

CE(sat)

0:100½200,

TEST CONDITION

=150V, I

=6V, I

=10mA, I

=5V, I

=200mA

=500mA, I

=50mA

=5V, I

=5mA

=5V, I

=200mA

=10V, I

=0, f=1MHz

Y:160½320

MIN.

160

0.45

TYP.

100

MAX.

1.0

320

1.5

0.75

MHz

UNIT

2008. 4. 16

Revision No : 2

1/3
