CUSTOMER DRAWING
Product Name
Product Dimensions
øA
øB
L
min
min
max
2.5
(0.098)
4.3
(0.169)
6.8
(0.267)
10.8
(0.425)
13.0
(0.512)
17.0
(0.669)
22.5
(0.885)
33.0
(1.299)
3.0
(0.118)
4.8
(0.189)
7.3
(0.287)
11.5
(0.452)
15.1
(0.594)
19.0
(0.748)
24.5
(0.964)
35.0
(1.380)
24.5
(0.964)
29.3
(1.153)
32.5
(1.279)
35.5
(1.397)
45.5
(1.79)
55.5
(2.165)
80.0
(3.149)
80.0
(3.149)
D
max
3.0
(0.118)
4.8
(0.189)
7.3
(0.287)
11.5
(0.452)
15.1
(0.594)
18.0
(0.748)
23.5
(0.925)
34.0
(1.338)
øE
min
1.5
(0.059)
2.0
(0.078)
3.3
(0.130)
4.5
(0.177)
7.0
(0.275)
9.0
(0.354)
12.0
(0.472)
19.0
(0.748)
Cable Dimensions
øF
øG
H0.5
min
max
(H0.020)
1.0
(0.039)
1.5
(0.059)
2.8
(0.110)
4.0
(0.157)
6.5
(0.256)
8.0
(0.315)
11.0
(0.433)
17.0
(0.689)
2.5
(0.098)
4.3
(0.169)
6.8
(0.267)
10.8
(0.425)
13.0
(0.512)
16.0
(0.630)
21.5
(0.846)
32.0
(1.259)
6.0
(0.236)
8.0
(0.315)
10.0
(0.393)
12.0
(0.472)
16.0
(0.630)
21.0
(0.827)
29.0
(1.142)
29.0
(1.142)
J0.5
(J0.020)
7.0
(0.275)
9.0
(0.354)
11.0
(0.433)
13.0
(0.512)
17.0
(0.669)
23.0
(0.905)
31.0
(1.220)
31.0
(1.220)
B-150-03
B-150-05
B-150-07
B-150-11
B-150-13
B-150-17
B-150-23
B-150-33
MATERIALS
1. INSULATION SLEEVE: Heat-shrinkable, transparent clear, radiation cross-linked modified polyolefin.
2. SOLDER PREFORM WITH FLUX.
SOLDER:
TYPE Cd18 per ANSI-J-STD-006.
FLUX:
TYPE ROM1 per ANSI-J-STD-004.
3. MELTABLE SEALING RINGS: Thermally stabilized thermoplastic.
APPLICATION
1. These controlled soldering devices are designed for termination of a bare or tin plated copper shield on a cable having an
insulation rated for at least +85C.
2. Temperature range: -55C to +125C.
For installation procedure and application equipment, consult RPIP-688-00.
For best results, prepare
the cable as shown:
