THIS DRAWING IS UNPUBLISHED.
RELEASED FOR PUBLICATION
BY TYCO ELECTRONICS CORPORATION.
ALL RIGHTS RESERVED.
3
21-FEB-1996
LOC
2
DIST
1
REVISIONS
P
LTR
DESCRIPTION
DATE
DWN
APVD
C
COPYRIGHT
1996
E
B
G
ECR-07-015707
ECR-10-010252
13/06/07
24/05/10
MJG
MJG
JA
JA
D
H
D
DIODE MARKER BAND THIS END
12
POLARIZING SLOT
12.8
C
11
13.1
1
MATERIALS
HOUSING :- NYLON 66
CONTACTS :- BRASS
C
17 MIN
17 MIN
8± 0.1
2 AMP PRODUCT SPEC No 108-3382.
3 AMP APPLICATION SPEC No 114-3185.
B
R3.4
1.8
RECOMMENDED PANEL
CUTOUT DIMS.
(CUTOUT TAB MAY BE)
(OMITTED IF POLARIZING)
(IS NOT REQUIRED)
B
SCALE 5:2
BULBHOLDER WITHOUT BULB
THIS DRAWING IS A CONTROLLED DOCUMENT FOR TYCO ELECTRONICS CORPORATION
IT IS SUBJECT TO CHANGE AND THE CONTROLLING ENGINEERING ORGANIZATION
SHOULD BE CONTACTED FOR THE LATEST REVISION.
349494-2
PART NUMBER
DWN
CHK
A.J.BEKEN
R.GOODALL
20FEB2002
20FEB2002
20FEB2002
NAME
DESCRIPTION
Tyco Electronics UK Ltd,
Stanmore, Middlesex, HA7 4RS.
DIMENSIONS:
A
RECOMMENDED MAXIMUM PANEL DENSITY
FOR MANUAL WIRE INSERTION TOOLS.
CONSULT AMP FOR PITCHING DIMENSIONS
IF USING POWERED TOOLS.
SCALE 1:1
PANEL THICKNESS 1.5 TO 2.0
AMP 1470-19 REV 31MAR2000
mm
TOLERANCES UNLESS
OTHERWISE SPECIFIED:
APVD
LINEAR
0 PLC
1 PLC
2 PLC
3 PLC
4 PLC
±
0.5
±
0.1
±
0.1
±
0.05
±
-
±
-
PRODUCT SPEC
R.GOODALL
108-3382
APPLICATION SPEC
±
0.5
5mm IDC BULBHOLDER ASSEMBLY
-
WITH DIODE
CAGE CODE
DRAWING NO
RESTRICTED TO
A
ANGLES
FINISH
MATERIAL
114-3185
WEIGHT
SIZE
-
1
-
-
CUSTOMER DRAWING
A3
00779
349494
SCALE
-
5:1
SHEET
1
OF
1
REV
H
