FAN: 40X40X10mm, 12V, 3 WIRE.
DOUBLE BALL BEARING TYPE.
REVISION(S)
LTR
O
A
B
DESCRIPTION
ECN: 0S60-0078-04
ECN: 0S60-0060-05
ECR-06-007721
INIT
APP'D
E.T 03/26/04 B.P 04/05/04
E.T 3/10/05 B.P 6/15/05
E.T 3/29/06 C.W 3/29/06
AIR FLOW DIRECTION
D
ALIGN SCREW
WITH HOLE
ALIGN SCREW
WITH HOLE
C
NOTE:
D
2
2.000 DIA.
PIN-FIN HS: 0.500 HT.
1. MATERIAL:
HEAT SINK: ALUM. (BLACK ANODIZE)
CLIP:
BLACK PEI (UL94-VO)
2. BEFORE THE HEATSINK APPLICATION, THE USER SHOULD
IDENTIFY THE SPECIFICATION OF MAXIMUM LOAD ON
THE BGA PACKAGE.
HEATSINK TORQUE SPECIFICATIONS CONVERTED TO FORCE.
BARE DIE PACKAGE:
2.5 INCH - LB TORQUE = 7.8 LBS FORCE
3.0 INCH - LB TORQUE = 9.4 LBS FORCE
FULL SIZE LID PACKAGE:
2.5 INCH - LB TORQUE = 6.3 LBS FORCE
3.0 INCH - LB TORQUE = 7.6 LBS FORCE
3. REMOVE CLIP WITH REMOVAL TOOL P/N: 1542616-1.
BLACK
RED
C
1
BLUE
4-LEG CLIP SIZE: 42.5mm
5
THE LENGTH
OF WIRE: 300mm
CONFIRM WIRE CONFIGURATION
AS SHOWN WITH CONNECTOR
TABS FACE UP
CONNECTOR: MOLEX 22-01-3027
2695-3PIN.
C
.012±.002
4. RoHS COMPLIANT AND CERTIFIED.
DETAIL C
SCALE 4 : 1
B
B
2.000 ±.020
DETAIL A
SCALE 6 : 1
.500
A
.290±.005
1 3/8" - 27 - UNS -2A
THREAD
WITH
FAN
2.51
2.36
2.42
MATERIAL:
3/25/04
DATE
.786 MAX
1.076
B
.098
.163 ±.005
B
1.679 LIP LEG
1.800
Power
5 Watts
10 Watts
15 Watts
DESCRIPTION
MOUNTING CLIP
HEAT SINK
FAN
SCREW
INTERFACE
1
2
3
4
5
1.686
SECTION B-B
° C/W @ ° C/W @ ° C/W @ ° C/W @
Ambient 200 LFM 400 LFM 600 LFM
8.64
7.86
7.38
QTY
1
1
1
2
1
ITEM
DO NOT SCALE
A
4.45
4.49
4.57
UNLESS OTHERWISE
SPECIFIED
TOLERANCES ARE:
.XX
.XXX
.XXXX
ANGLES
.
.
.
2.80
2.89
2.95
DRAWN BY:
2.00
2.38
2.42
DATE
CUSTOMER DRAWING
SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT NOTICE
CONFIDENTIAL PROPERTY OF TYCO
ELECTRONICS. NOT TO BE DISCLOSED
TO OTHERS. REPRODUCED OR USED FOR
ANY PURPOSES EXCEPT AS AUTHORIZED
IN WRITING BY AN AUTHORIZED OFFICIAL
OF TYCO. MUST BE RETURNED TO TYCO
ON DEMAND, ON COMPLETION OF ORDERS
OR OTHER PURPOSES FOR WHICH LENT.
DIMENSONS ARE IN:
TITLE:
A
42.5mm HS ASS'Y
(HTS270B-U)
3-1542006-9
SHEET:
E.TAO
ENGINEER:
SEE NOTE
FINISH:
B. PETROCELLI
FILENAME
PROJECT
04/05/04
SYSTEM
INCHES
SEE NOTE
TNIRD ANGLE
PROJECTION
SCALE:
1:1
SIZE:
PART NO:
1 OF 1
REV:
A
DWG. NO.
8
7
C-3-1542006-9
B
