1. Im is the maximum peak current for which the output voltage specifications are guaranteed, however the If RMS rating must not be exceeded.
2. All specifications measured at 25°C, Rl=10 kΩ, unless otherwise noted.
3. It is recommended to add a 1 μF capacitor connected between the common terminal 4 and the +12 V and -12 V terminals, 1 and 2, to avoid noise problems.
SPECIFICATIONS
parameter
supply voltage (Vcc)
max current consumption (Ic)
output voltage (Vo)
zero current offset voltage (Vr)
output voltage linearity
4
(ΔKo)
response (tr)
output voltage temperature
characteristics
zero current offset voltage
characteristics
hysteresis (Vh)
primary over current
withstand voltage
insulation resistance
operating temperature
storage temperature
safety approvals
flammability rating
RoHS
Notes:
conditions/description
min
±11.4
typ
±12.0
±4.00
0
3
max
±12.6
25
±4.04
+0.03
±0.5
units
V
mA
V
V
%
μs
at +If
after demagnetization
at di/dt = If/μs
±3.96
-0.03
±0.1
±1.5
at +If to zero current
for maximum 50 ms, no damage
between coil and each terminal for 1 minute
between coil and each terminal at 500 Vdc
-10
-30
UL 508
UL94V-0
yes
2,000
500
75
90
15
10*If
%/°C
mV/°C
mV
A
Vac
MΩ
°C
°C
4. Deducting the value of hysteresis and offset voltage, calculated by (V/Vo)/(IfxI-1)x100%.
cuidevices.com
Additional Resources:
Product Page
|
3D Model
|
PCB Footprint
CUI Devices
│
SERIES:
CSXX120B
│
DESCRIPTION:
CURRENT SENSOR
date
02/19/2020
│
page
2 of 4
SOLDERABILITY
parameter
hand soldering
conditions/description
for maximum 3 seconds
min
typ
280
max
units
°C
MECHANICAL
parameter
dimensions
case material
terminals
weight
conditions/description
15 x 15 x 20
PBT
phosphor bronze with tin plating
8
g
min
typ
max
units
mm
MECHANICAL DRAWING
units: mm
tolerance: ±0.5 mm
PIN CONNECTIONS
PIN
1
2
3
4
5
6
FUNCTION
+12 V
-12 V
Output (V)
0 V
+Input (A)
-Input (A)
ØA
(mm)
0.6
0.9
1.1
1.4
1.7
ØB
(mm)
1.2
1.5
1.7
2.0
2.3
①② ③ ④
⑤
⑥
MODEL NO.
CS03120B
CS05120B
CS10120B
CS15120B
CS20120B
Recommended PCB Layout
Top View
cuidevices.com
Additional Resources:
Product Page
|
3D Model
|
PCB Footprint
CUI Devices
│
SERIES:
CSXX120B
│
DESCRIPTION:
CURRENT SENSOR
date
02/19/2020
│
page
3 of 4
DERATING CURVE
Temperature Derating Curve
(Natural Convection)
100
80
60
40
20
0
-10
Rated Current (%)
0
20
30
40 45 50
60
70 75 80
Ambient Temperature (°C)
PERFORMANCE CURVES
Output Voltage vs. Input Current
Input Current Frequency vs. Output Attenuation
Input Current (A)
Output Voltage vs. Ambient Temperature
(at +If)
Frequency Input Current (Hz)
Offset Voltage vs. Ambient Temperature
(at Zero Current)
Ambient Temperature (°C)
Ambient Temperature (°C)
cuidevices.com
Additional Resources:
Product Page
|
3D Model
|
PCB Footprint
CUI Devices
│
SERIES:
CSXX120B
│
DESCRIPTION:
CURRENT SENSOR
date
02/19/2020
│
page
4 of 4
REVISION HISTORY
rev.
1.0
1.01
description
initial release
brand update
date
09/03/2019
02/19/2020
The revision history provided is for informational purposes only and is believed to be accurate.
CUI Devices offers a one (1) year limited warranty. Complete warranty information is listed on our website.
CUI Devices reserves the right to make changes to the product at any time without notice. Information provided by CUI Devices is believed to be accurate and reliable. However, no
responsibility is assumed by CUI Devices for its use, nor for any infringements of patents or other rights of third parties which may result from its use.
CUI Devices products are not authorized or warranted for use as critical components in equipment that requires an extremely high level of reliability. A critical component is any
component of a life support device or system whose failure to perform can be reasonably expected to cause the failure of the life support device or system, or to affect its safety or
