Datasheet> All Categories > Passive components> inductor> 1-1624113-0

Preview

1-1624113-0: Description1 ELEMENT, 0.027uH, GENERAL PURPOSE INDUCTOR, SMD, CHIP, 1008, ROHS COMPLIANT; CategoryPassive components inductor; File Size100KB，1 Pages; ManufacturerTE Connectivity; Websitehttp://www.te.com; Environmental Compliance; Related ProductsFound2parts with similar functions to 1-1624113-0

Download Datasheet Parametric Compare View All

1-1624113-0 Overview

1 ELEMENT, 0.027uH, GENERAL PURPOSE INDUCTOR, SMD, CHIP, 1008, ROHS COMPLIANT

1-1624113-0 Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
package instruction	1008
Reach Compliance Code	unknow
ECCN code	EAR99
uppercase and lowercase codes	1008
DC Resistance	0.13 Ω
Nominal inductance(L)	0.027 µH
Inductor type	GENERAL PURPOSE INDUCTOR
Manufacturer's serial number	3650
Number of functions	1
Number of terminals	2
Minimum quality factor (at nominal inductance)	55
Maximum rated current	1 A
Shape/Size Description	RECTANGULAR PACKAGE
shield	NO
surface mount	YES
Terminal location	DUAL ENDED
Terminal shape	WRAPAROUND
Tolerance	5%
Base Number Matches	1

Preview

Download Datasheet

View All

C orporate Hom e

|

Electronic Components

|

Se gm e nts

|

W ho W e Are

My Account

Searc h

Products

Documentation

Resources

My Account

Customer Support

Home

>

Products

>

By Type

>

Passive C omponents

>

Product Feature Selector

> Product Details

36502C027J Product Details

Live Product Chat

Inductors

C onve rte d to EU R oHS/ELV C om plia nt

(

Sta te m e nt of C om plia nce

)

Quick Links

C heck Pricing & Availability

Search for Tooling

Product Feature Selector

C ontact Us About This Product

36502C027J

(1-1624113-0)

T E I nternal N umber: 1 - 1 6 2 4 1 1 3 - 0

Product Highlights:

l

Inductor

l

Inductor Type = High Frequency

l

Lead Type = Surface Mount Terminals

l

Wirewound

l

Inductance = .027 ?H

View all Features

A dd to M y P art L is t

Reques t Sample

Find Similar P roduc ts

Obsolete

C ontact Product Information C enter

Buy P roduc t

Documentation & Additional Information

Product Drawings:

l

None Available

Catalog Pages/Data Sheets:

l

Low Inductance, High Frequency C hip Inductors - Type...

(PDF, English)

Product Specifications:

l

None Available

Application Specifications:

l

None Available

Instruction Sheets:

l

None Available

CAD Files:

l

None Available

List all Documents

Product Features

(Please use the Product Drawing for all design activity)

Product Type Features:

l

Product Type

= Inductor

l

Inductor Type = High Frequency

l

Element

= Wirewound

l

Shielded

= No

Electrical Characteristics:

l

Inductance (?H)

= 0.027

l

DC Resistance (?)

= 0.13

l

C urrent, Maximum (mA)

= 1000

l

Quality Factor

= 55

l

Package Type

= Taped and Reeled

l

Tolerance (%) = 5

Body Related Features:

l

Lead Type

= Surface Mount Terminals

l

Series

= 3650

l

Packaging Style

= 1008

l

Package, C omponent Size

= 2.5 x 2.0

l

Mount Style

= Surface Mount

Industry Standards:

l

RoHS/ELV C ompliance

= RoHS compliant, ELV compliant

l

Lead Free Solder Processes

= Reflow solder capable to 245?C ,

Reflow solder capable to 260?C

l

RoHS/ELV C ompliance History = C onverted to comply with RoHS

directive

Operation/Application:

l

Application

= High Frequency

Other:

l

Brand = Sigma Inductors

Additional Information:

l

Product Line Information

1-1624113-0 Related Products

	1-1624113-0	36502C027J
Description	1 ELEMENT, 0.027uH, GENERAL PURPOSE INDUCTOR, SMD, CHIP, 1008, ROHS COMPLIANT	1 ELEMENT, 0.027uH, GENERAL PURPOSE INDUCTOR, SMD, CHIP, 1008, ROHS COMPLIANT
Is it Rohs certified?	conform to	conform to
package instruction	1008	1008
Reach Compliance Code	unknow	unknown
ECCN code	EAR99	EAR99
uppercase and lowercase codes	1008	1008
DC Resistance	0.13 Ω	0.13 Ω
Nominal inductance(L)	0.027 µH	0.027 µH
Inductor type	GENERAL PURPOSE INDUCTOR	GENERAL PURPOSE INDUCTOR
Manufacturer's serial number	3650	3650
Number of functions	1	1
Number of terminals	2	2
Minimum quality factor (at nominal inductance)	55	55
Maximum rated current	1 A	1 A
Shape/Size Description	RECTANGULAR PACKAGE	RECTANGULAR PACKAGE
shield	NO	NO
surface mount	YES	YES
Terminal location	DUAL ENDED	DUAL ENDED
Terminal shape	WRAPAROUND	WRAPAROUND
Tolerance	5%	5%
Base Number Matches	1	1
