NPN-SWITCHING SILICON TRANSISTOR
Qualified per MIL-PRF-19500/251
DEVICES
LEVELS
2N2218
2N2218A
2N2218AL
2N2219
2N2219A
2N2219AL
See datasheet for JANSR2N2218 &
JAN
JANTX
JANTXV
JANS *
*
Also available in Radiation Hardened versions.
JANSR2N2219
ABSOLUTE MAXIMUM RATINGS
(T
C
= +25°C unless otherwise noted)
Parameters / Test Conditions
Collector-Emitter Voltage
Collector-Base Voltage
Emitter-Base Voltage
Collector Current
@ T
A
= +25°C
@ T
C
= +25°C
Operating & Storage Junction Temp. Range
Total Power Dissipation
THERMAL CHARACTERISTICS
Parameters / Test Conditions
Thermal Resistance, Junction-to-Case
Symbol
R
θJC
Value
59
Unit
°C/W
Symbol
V
CEO
V
CBO
V
EBO
I
C
P
T
T
op
, T
stg
2N2218
2N2219
30
60
5.0
2N221A; L
2N2219A; L
50
75
6.0
800
0.8
3.0
-55 to +200
Unit
Vdc
Vdc
Vdc
mA
W
W
°C
TO-39 (TO-205AD)
2N2218, 2N2218A
2N2219, 2N2219A
Note:
(1) Derate linearly 4.6mW/°C above T
A
> +25°C
(2) Derate linearly 17.0mW/°C above T
C
> +25°C
ELECTRICAL CHARACTERISTICS
(T
A
= +25°C, unless otherwise noted)
Parameters / Test Conditions
OFF CHARACTERTICS
Collector-Emitter Breakdown Voltage
I
E
= 10mAdc
2N2218; 2N2219
2N2218A; 2N2219A / AL
Emitter-Base Cutoff Current
V
EB
= 5.0Vdc
V
EB
= 6.0Vdc
V
EB
= 4.0Vdc
Collector-Base Cutoff Current
V
CE
= 30Vdc
V
CE
= 50Vdc
2N2218; 2N2219
2N2218A; 2N2219A / AL
All Types
2N2218; 2N2219
2N2218A; 2N2219A / AL
V
(BR)CEO
30
50
10
10
10
10
10
Vdc
TO-5
2N2218AL
2N2219AL
Symbol
Min.
Max.
Unit
I
EBO
μAdc
ηAdc
I
CES
ηAdc
T4-LDS-0091 Rev. 2 (101484)
Page 1 of 4
TECHNICAL DATA SHEET
6 Lake Street, Lawrence, MA 01841
1-800-446-1158 / (978) 620-2600 / Fax: (978) 689-0803
Website: http://www.microsemi.com
Gort Road Business Park, Ennis, Co. Clare, Ireland
Tel: +353 (0) 65 6840044 Fax: +353 (0) 65 6822298
ELECTRICAL CHARACTERISTICS
(T
A
= +25°C, unless otherwise noted) (Con’t)
Parameters / Test Conditions
Collector-Base Cutoff Current
V
CB
= 50Vdc
V
CB
= 60Vdc
V
CB
= 60Vdc
V
CB
= 75Vdc
ON CHARACTERTICS (3)
Forward-Current Transfer Ratio
I
C
= 0.1mAdc, V
CE
= 10Vdc
2N2218; 2N2219
2N2218; 2N2219
2N2218A; 2N2219A / AL
2N2218A; 2N2219A / AL
Symbol
Min.
Max.
10
10
10
10
Unit
ηAdc
μAdc
ηAdc
μAdc
I
CBO
I
C
= 1.0mAdc, V
CE
= 10Vdc
I
C
= 10mAdc, V
CE
= 10Vdc
I
C
= 150mAdc, V
CE
= 10Vdc
I
C
= 500mAdc, V
CE
= 10Vdc
Collector-Emitter Saturation Voltage
I
C
= 150mAdc, I
B
= 15mAdc
I
C
= 500mAdc, I
B
= 50mAdc
Base-Emitter Saturation Voltage
I
C
= 150mAdc, I
B
= 15mAdc
2N2218
2N2219
2N2218A; 2N2218AL
2N2219A; 2N2219AL
2N2218
2N2219
2N2218A; 2N2218AL
2N2219A; 2N2219AL
2N2218
2N2219
2N2218A; 2N2218AL
2N2219A; 2N2219AL
2N2218; A; AL
2N2219; A; AL
2N2218; A; AL
2N2219; A; AL
2N2218; 2N2219
2N2218A; 2N2219A / AL
h
FE
20
35
30
50
25
50
35
75
35
75
40
100
40
100
20
30
150
325
150
325
120
300
0.4
0.3
V
CE(sat)
Vdc
1.6
1.0
2N2218; 2N2219
2N2218A; 2N2219A / AL
2N2218; 2N2219
2N2218A; 2N2219A / AL
V
BE(sat)
2N2218; 2N2219
2N2218A; 2N2219A / AL
0.6
0.6
1.3
1.2
Vdc
2.6
2.0
I
C
= 500mAdc, I
B
= 50mAdc
T4-LDS-0091 Rev. 2 (101484)
Page 2 of 4
TECHNICAL DATA SHEET
6 Lake Street, Lawrence, MA 01841
1-800-446-1158 / (978) 620-2600 / Fax: (978) 689-0803
Website: http://www.microsemi.com
Gort Road Business Park, Ennis, Co. Clare, Ireland
Tel: +353 (0) 65 6840044 Fax: +353 (0) 65 6822298
DYNAMIC CHARACTERISTICS
Parameters / Test Conditions
Magnitude of Small-Signal Forward Current Transfer Ratio
I
C
= 20mAdc, V
CE
= 20Vdc, f = 100MHz
Small-Signal Forward Current Transfer Ratio
I
C
= 1.0mAdc, V
CE
= 10Vdc, f = 1.0kHz
2N2218
2N2219
2N2218A, AL
2N2219A, AL
Output Capacitance
V
CB
= 10Vdc, I
E
= 0, 100 kHz
≤
f
≤
1.0MHz
Input Capacitance
V
EB
= 0.5Vdc, I
C
= 0, 100 kHz
≤
f
≤
1.0MHz
SWITCHING CHARACTERISTICS
Parameters / Test Conditions
V
CC
= 30Vdc; I
C
= 150mAdc; I
B1
= 15mAdc
Turn-On Time
(See Figure 3 of MIL-PRF-19500/251)
Turn-Off Time
(See Figure 4 of MIL-PRF-19500/251)
Symbol
Min.
Max.
Unit
Symbol
|h
fe
|
Min.
2.5
25
50
35
75
8.0
25
pF
pF
Max.
12
Unit
h
fe
C
obo
C
ibo
2N2218, 2N2219
2N2218A, 2N2219A / AL
2N2218, 2N2219
2N2218A, 2N2219A / AL
t
on
40
35
250
300
ηs
t
off
ηs
(3) Pulse Test: Pulse Width = 300μs, Duty Cycle
≤
2.0%.
T4-LDS-0091 Rev. 2 (101484)
Page 3 of 4
TECHNICAL DATA SHEET
6 Lake Street, Lawrence, MA 01841
1-800-446-1158 / (978) 620-2600 / Fax: (978) 689-0803
Website: http://www.microsemi.com
Gort Road Business Park, Ennis, Co. Clare, Ireland
Tel: +353 (0) 65 6840044 Fax: +353 (0) 65 6822298
PACKAGE DIMENSIONS
Dimensions
Inches
Millimeters
Min
Max
Min
Max
.305
.335
7.75
8.51
.240
.260
6.10
6.60
.335
.370
8.51
9.40
.200 TP
5.08 TP
.016
.019
0.41
0.48
See note 14
.016
.019
0.41
0.48
.050
1.27
.250
6.35
.100
2.54
.030
0.76
.029
.045
0.74
1.14
.028
.034
0.71
0.86
.010
0.25
45° TP
45° TP
Symbol
CD
CH
HD
LC
LD
LL
LU
L
1
L
2
P
Q
TL
TW
r
α
Notes
7
8, 9
8, 9
8, 9
8, 9
7
5
3, 4
3
10
7
NOTES:
1. Dimensions are in inches.
2. Millimeters are given for general information only.
3. Beyond r (radius) maximum, TW shall be held for a minimum length of .011 (0.28 mm).
4. Dimension TL measured from maximum HD.
5. Body contour optional within zone defined by HD, CD, and Q.
6. CD shall not vary more than .010 inch (0.25 mm) in zone P. This zone is controlled for automatic handling.
7. Leads at gauge plane .054 +.001 -.000 inch (1.37 +0.03 -0.00 mm) below seating plane shall be within .007 inch (0.18 mm)
radius of true position (TP) at maximum material condition (MMC) relative to tab at MMC.
8. Dimension LU applies between L1 and L2. Dimension LD applies between L2 and LL minimum. Diameter is uncontrolled
in L1 and beyond LL minimum.
9. All three leads.
10. The collector shall be internally connected to the case.
11. Dimension r (radius) applies to both inside corners of tab.
12. In accordance with ASME Y14.5M, diameters are equivalent to
φx
symbology.
13. Lead 1 = emitter, lead 2 = base, lead 3 = collector.
14. For L suffix devices (TO-5), dimension LL = 1.5 inches (38.10 mm) min. and 1.75 inches (44.45 mm) max. For non-L
suffix types (TO-39), dimension LL = .5 inch (12.70 mm) min. and .750 inch (19.05 mm) max.
FIGURE 1.
Physical dimensions (similar to TO-39, TO-5).
T4-LDS-0091 Rev. 2 (101484)
Page 4 of 4
